Clay Paky AXCOR300S Moving Spot Light

Clay Paky AXCOR300S Moving Spot Light

The new Axcor 300 family of moving LED fixtures brings Claypaky’s no-compromise quality and performance to the broad mid-market. The quality of their effects, their construction, and their high light output derive from the high-end products Claypaky specializes in.

The AXCOR SPOT 300 has 17 gobos on 2 wheels, including 7 high quality dichroic rotating gobos. Weighing just 20 Kg and measuring a little over 500 mm, this unit incorporates features that are not often found in models of this size, like a rotating prism, a motorised iris, a soft edge filter, a 16-bit dimmer, and a 8-40° zoom.

&It boasts cutting- edge electronic and software technology, with all the features that enable optimal fixture management and maintenance over time.With a price-point, physical size and power consumption that disguise its strength and creative potential, the Axcor Spot 300 enables a new world of expression in touring, events, TV, theatre and installed lighting markets.

Features:

• Source: 180W White LED engine (7000 K)
• 8°-40° linear zoom
• Motorised focus lens
• CMY System
• One color wheel with 7 colors (including 1 CTO filter)
• One wheel with 7 rotating gobos
• One wheel with 10 fixed gobos
• Rotating 4-facet prism
• Mechanical Iris
• Frost filter
• 16-bit Electronic Dimmer with 4 curves
• Electronic strobe@24 f/sec
• Extremely compact and lightweight

Specifications:

• Power Supplies:
  • AC power input Neutrik PowerCON
  • 100-240V, 50/60 Hz
• Input Power:
  • 340 VA @230Vac - 50Hz
  • Total Lumen output: 7000 lumens
• Light Source:
  • 180W White LED engine (7000 K)
• Optics:
  • 8°-40° linear zoom
  • Motorised focus lens
• Color System:
  • CMY System
  • One color wheel with 7 colors (including 1 CTO filter)
• EFffects Section:
  • One wheel with 7 rotating gobos
  • One wheel with 10 fixed gobos
  • Rotating 4-facet prism
  • Mechanical Iris
  • Frost filter
• Control andg Programming:
  • 23 DMX 512 control channels
  • Control signal USITT DMX 512
  • Protocols RDM, WebServer
  • Display Graphic LCD backlit b/w Display
  • Display battery self-charging buffer battery
  • 16-bit Electronic Dimmer with 4 curves
  • Electronic strobe@24 f/sec
  • Pan/Tilt Resolution 16 bit
  • Dimmer Resolution 16 bit
  • DMX signal connection 5 pole XLR input and output
• Body:
  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • Device locking PAN and TILT mechanisms for transportation and maintenance
• Moving Body:
  • PAN range 540°
  • TILT range 270°
• Electronics:
  • Long life self-charging buffer battery
  • Function reset from the lighting desk
  • “AUTOTEST” function from menu
  • Electronic monitoring with status error
  • Cooling system monitoring
  • DMX level monitoring on all channels
  • Internal data transmission diagnostics
  • Firmware Upgrade via Web Server
  • Firmware upload from another fixture
  • Protocols/Functions: RDM, Web Server
