ADJ American DJ Focus Spot 2X 100W LED Moving Head Light w/UV
The ADJ Focus Spot 2X is a 100W LED Moving Head with a 3W UV LED included for black lighting or additional color hues. It features two prism effects; a 6-facet circular prism and a 6-facet linear prism. In addition, ADJ has fitted the FS2X with a GOBO wheel with replaceable, rotating and indexable GOBOs. The GOBOs are easy to replace by removing the top housing with one screw that’s on a hinge. GOBOs easily lock in and out of the GOBO wheel. This mover is also equipped with motorized focus, Gobo Indexing, EZ Gobo replacement and a manual zoom knob near the lens to change the beam angle from 16 ~ 19 degrees.
The Focus Spot 2X is extremely versatile and has everything clubs, theaters, churches, concert productions and lighting professionals are looking for in a LED spot moving head. It has 16 & 18 DMX channel modes, Pan/Tilt Inversion, 16-Bit Fine Pan/Tilt, 3-pin DMX In/Out, locking In/Out power connectors, and a 4-Button DMX LCD menu.
The Focus Spot 2X is fitted with 8 colors plus spot and split colors. It has 6 rotating, replaceable GOBO patterns plus spot. The color wheel and GOBO wheel work independent of each other. All GOBOs are indexable.
Specifications:
- Light Source:
- 1 x 100W Cold White LED (7600˚K, 50,000 hr.)
- 1 x 3W UV LED
- Features:
- Motorized Focus
- Manual Zoom knob on head: 16 ~ 19 degree beam angle
- Fan cooled
- Strobe/Pulse effect; random strobe slow to fast
- UC IR & Airstream IR Compatible (Sold Separately)
- Color Wheel:
- 8 Colors + White & Split Colors
- GOBO Wheel:
- 6 Rotating, replaceable Gobos + Spot
- Gobo Size: Outer: 23mm/Inner:19mm/Thickness: 0.5mm
- Gobo Indexing
- EZ Gobo replacement with hinged head cover
- Gobo Shake effect
- Prism Wheel:
- 6-facet circular prism
- 6-facet linear prism
- Control:
- 3 Operational Modes: Sound Active, Show Mode, & DMX Controlled
- Master / Slave-able
- 4 Built-in lighting shows
- 16 & 18 DMX channel modes
- Electronic Dimming: 0% - 100%
- 5 Dimmer Curves
- 4-Button DMX LED menu
- Stepper motors with micro stepping
- With Wired Digital Communication Network
- Connections:
- 3-pin DMX In/Out
- Twist locking power In/Out connections on rear to daisy chain power (up to 9 Focus Spot 2X’s @ 120V and 16 Focus Spot 2X’s @ 230V)
- Pan/Tilt:
- Fast and precise Pan/Tilt Movements
- 16-Bit Fine Pan/Tilt control
- Pan: 540-degree
- Tilt: 270-degree
- Pan/Tilt Invert Mode
- 4, Built-In, Pan/Tilt Target Modes
- Electrical:
- Multi-voltage Operation: 100-240V, 50Hz/60Hz
- Power Consumption: 180W
- Dimensions / Weight:
- Dimensions (LxWxH): 9.33” x 9.10” x 15.15”/ 237 x 231 x 385mm
- Weight: 14.5 lbs. / 6.5 kgs.
- What’s Included:
- Includes Omega bracket for truss mounting
- Includes power cable
- Approvals:
- CE
- ETL (Pending)
