Description

Chauvet Legend 230SR Beam 230-Watt Moving Yoke

Legend 230SR Beam features a 230-watt Osram Sirius lamp outputting an intense 96,000 lux at 15 meters, thanks to precision glass optics and a tiny 2.25-degree beam angle. Compact and agile, it also features a zooming 8-facet prism and 17 gobos (plus open) for beam shaping effects, along with automated focus. In addition to 14 solid colors plus white, the color wheel delivers seamless split colors.

Features:
  • Compact moving yoke beam fixture with a zoomable prism and motorized focus
  • Uses Osram Sirius 230W Lamp source with a rated 3000 hour lamp life
  • Precision designed optics for hard edged beam effects
  • Variable frost for wash style effects
  • Extremely quiet for operation in any situation
  • Fast and precise pan and tilt movement
  • 8 facet rotating prism with zoom for stunning effects
  • 3- and 5-pin DMX input and output connectors
  • powerCON power input
Specifications:
  • DMX Channels: 15 or 18
  • DMX Connectors: 3- and 5-pin
  • Pan and Tilt: 540 degrees/270 degrees
  • Colors: 14 + white, split colors, continuous scroll at variable speeds
  • Gobos: 17 + open, continuous scroll at variable speeds
  • Light Source: Osram Sirius 230W lamp (3000 hour lamp life)
  • Strobe Rate: 0 - 20Hz
  • Beam Angle: 2.25 degrees
  • Illuminance: 96,000 lux @ 15m
  • IP Rating: IP20
  • Cable Length: 5ft (1.5m)
  • Power Input: powerCON
  • Input Voltage: Auto-ranging 100 - 240VAC 50/60Hz
  • Power and Current: 415W, 3.43A @ 120V 60Hz
  • Power and Current: 401W, 2.02A @ 208V 60Hz
  • Power and Current: 385W, 1.75A @ 230V 50Hz
  • Weight: 41.3lbs (18.7kg)
  • Size: 13.5 x 16.4 x 19.6in (343 x 415 x 498mm)
  • Approvals: CE, MET
