Description

Chauvet COLORdash Par-Quad 18 RGBA LED Fixture

COLORdash Par Quad-18 is powered by 18 quad-colored RGBA LEDs in a compact and durable housing. Amber LEDs help produce any variation of white and stunning saturated colors for an expansive palette devoid of multi-colored shadows. A split-yoke bracket eliminates the need for floor stands. Power linking, a locking IEC power input, as well as 3- and 5-pin DMX connectors simplify connections and setup. COLORdash Par Quad-18 also includes a built-in gel frame holder.

Features:
  • DMX channels: 4, 6, 10-channel
  • Operating modes: 4-channel: RGBA, 6-channel: Dimmer, RGBA, strobe, 10-channel: Dimmer, RGBA, strobe, macro, auto, auto speed, dim mode
  • Silent flicker free operation
  • Lightweight, easy to install
  • 16 bit dimming with selectable dimming curves
  • All metal construction for added durability
Specifications:
  • DMX connectors: 3-pin & 5-pin
  • Source: 18 (5 W) quad-color LEDs, 50,000 hours
  • Light source: red (444mA x 2.09vdc = 0.93W), Green (466mA x 3.48vdc = 1.62W), Blue (480mA x 2.98vdc = 1.43W), Amber (495mA x 2.40vdc = 1.19W)
  • Beam angle: 18 degrees
  • Field angle: 32.5 degrees
  • Illuminance: 1,210 lux @ 5 m
  • Power linking: 14 units @ 120 V / 24 units @ 208 V/ 26 units @ 230 V
  • Input voltage: auto-ranging 100-240 VAC 50/60 Hz
  • Power and current: 113 W, 0.95 A @ 120 V 60 Hz
  • Power and current: 115 W, 0.56 A @ 208 V 50 Hz
  • Power and current: 117 W, 0.51 A @ 230 V 50 Hz
  • Weight: 10.2 lbs (4.6 kg)
  • Size: 12.7 x 11.7 x 4.1 in (323 x 298 x 106 mm)
  • Approvals: CE
