Description

Chauvet COLORADO-1-QUAD-TOUR DMX LED Wash Light

Powered by seven quad-colored LEDs, COLORado 1-Quad Tour is a compact, tour-ready wash light with a truer white spectrum, a vast color palette ranging from vivid hues to soft pastels and five dimming curves. A split yoke bracket allows floor or truss mounting and Neutrik powerCON connectors facilitate fast and secure set up. COLORado 1-Quad Tour also includes a built-in gel frame holder.

Features:
  • 3, 4, 5, 6 or 10 Quad Color LED wash light
  • Operating modes:
      3-channel: Red, Green, Blue (ARC 1)
      3-channel: Hue, Saturation, Value (HSV)
      4-channel: Dimmer, Red, Green, Blue (ARC 1+D)
      4-channel: Red, Green, Blue, White (ARC 2)
      5-channel: Dimmer, Red, Green, Blue, White (ARC 2+D)
      6-channel: Dimmer, Red, Green, Blue, White, Strobe (ARC 2+S)
      10-channel: Dimmer, Red, Green, Blue, White, Color Macro, Strobe, Auto Programs, Auto Speed Adjust, Dimmer Speed (TOUR)
  • RGBW color mixing with or without DMX control
  • Color temperature presets 3,200 ~ 10,000 K
  • Built-in automated programs via master/slave, DMX
  • Recall custom programs via master/slave or DMX
  • Five distinct dimming curves
  • RGBW Quad Color LEDs
  • Electronic dimmer
  • Color macros with speed adjustment included
  • Electronic power supply
  • Neutrik powerCon connectors
  • LED display with password protection
  • Double-bracket yoke doubles as floor stand
  • Color Calibration
Specifications:
  • DMX connectors: 3-pin and 5-pin
  • Source: 7 (10 W) quad-color LEDs, 50,000 hours
  • Light source: Red (692mA x 2.58vdc = 1.79W), Green (687mA x 3.90vdc = 2.68W), Blue (685mA x 3.69vdc = 2.53W), White (681mA x 3.63vdc = 2.47W)
  • Strobe Speed: 0 - 20hz
  • Beam Angle: 11.5 degrees
  • Field Angle: 25 degrees
  • Lux: 1,650 @ 5 m
  • AC Voltage Range: 100~240 V, 50/60 Hz (auto-ranging)
  • Power Consumption 120 V, 60 Hz: 66 W, 0.6 A (operating)
  • Power Consumption 230 V, 50 Hz: 65 W, 0.3 A (operating)
  • Power linking: 10 units @ 120 V (max.) / 18 units @ 230 V (max.)
  • Dimensions: 8.7 x 9.3 x 13.1 in (222 x 235 x 335mm)
  • Weight: 11.5 lbs (5.2 kg)
  • Power Connection: NEUTRIK powerCON power input and output connector
  • Certification: CE, MET
  • Environment: IP20, dry location
  • Cabling: NEUTRIK powerCON extension (18 in, 5/10/25 ft)
