Electro-Voice ZLX-12-G2 12-Inch 2-Way Passive Speaker
The new ZLX-G2 professional audio loudspeaker series is the next generation of the best-selling speakers from Electro-Voice, which raises the standard for performance and features in its class.
ZLX-G2 loudspeakers offer the best-in-class acoustic output. Electro-Voice-patented Signal Synchronized Transducers (SST) baffle design ensures improved bass, small size, and even coverage across all frequencies.
ZLX-12-G2 uses industry standard NL4 connections. The two NL4 connectors are in parallel and pass through all pins.
For optimal acoustics and performance, ZLX-12-G2 is recommended to be used with a Dynacord DSP power amplifier programmed with the appropriate speaker settings included in the EV Speaker Database for SONICUE.
Features:
- ZLX-G2 is the next generation of the bestselling pro-audio loudspeaker series from Electro-Voice
- Increased maximum SPL output and extended frequency response
- Robust and ergonomic design for day-to-day durability and portability
- Recommended to use with Dynacord DSP power amplifiers
- SONICUE integration - optimized speaker settings for best performance
Specifications:
- Frequency response (-3 dB) (Hz): 69 Hz – 18,500 Hz
- Frequency range (-10 dB) (Hz): 55 Hz – 20,000 Hz
- Axial sensitivity (dB SPL 1W/1m): 93 dB SPL 1W/1m
- Maximum sound pressure level at a distance of 1 m (dB) 1: 125 dB
- High pass frequency (Hz): 48 Hz
- Crossover frequency (kHz): 2 kHz
- Coverage angle HxV (°): 90° x 60°
- Power handling (continuous) (W): 250 W
- Power handling (peak) (W): 1,000 W
- Nominal impedance (Ω): 8 Ω
- LF transducer: WECA2128
- LF transducer size (in): 12 in
- LF transducer magnet material: Ferrite
- HF transducer: DH-1K
- HF transducer type: Compression driver
- HF transducer size (in): 1.4 in
- HF transducer diaphragm material: Titanium
- Dimensions (H x W x D) (mm): 621.1 mm x 356.2 mm x 356 mm
- Dimensions (H x W x D) (in): 24.45 in x 14.02 in x 14.01 in
- Shipping dimensions (H x W x D) (mm): 670 mm x 420 mm x 405 mm
- Shipping dimensions (H x W x D) (in): 26.38 in x 16.54 in x 15.94 in
- Weight (kg): 14.26 kg
- Weight (lb): 31.44 lb
- Shipping weight (kg): 16.26 kg
- Shipping weight (lb): 35.85 lb
