d&b audiotechnik 24C-E Column Loudspeaker
The 24C-E features six 4” neodymium drivers, providing an extension of vertical directivity down by a further octave to 190 Hz.
The loudspeaker is design provides a broadband attenuation to the rear of approximately 18 dB.
The 24C-E is available in black or white and weather-resistant.
Features:
- Components 6 x 4"
- Dispersion 90° x 20°
- SPLmax 128 dB
- Weight 7 kg / 15.4 lb
Specifications:
- System data:
- Frequency response (-5 dB standard): 110 Hz - 17 kHz
- Frequency response (-5 dB CUT mode): 150 Hz - 17 kHz
- Max. sound pressure: 128 dB (in combination with 24C)
- Cabinets per amplifier channel: 1
- Loudspeaker data:
- Configuration: Installation specific cardioid column extender
- Power handling capacity (RMS/peak 10 ms): 250/1200 W
- Vertical downtilt of low-mid beam: 5°
- Vertical adjustment of HF section: 0° ‒ -14°
- Nominal dispersion angle (h x v): 90° x 20°
- Components: 6 x 4" driver with neodymium magnet
- Connections: fixed cable gland with 2-pole Mate-N-Lok mini through 24C
- Dimensions / Weight:
- Dimensions (H x W x D): 701 x 124.5 x 124 mm / 27.6 x 4.9 x 4.88"
- Weight: 7 kg / 15.4 lb
