Panasonic AWHE120KPMH HD Robocam

Panasonic AWHE120KPMH HD Robocam

A high definition, remotely controllable PTZ camera. This camera is an effective solution for use in institutional and business settings, houses of worship, indoor sports facilities, and for high resolution monitoring of a variety of spaces. The 3x 1/3" 2.2 MP U.L.T. MOS Sensors allow this camera to capture sharp, high definition imagery in a range of formats from 1080/60i to 480/60p. The quick and accurate pan/tilt range offers a wide variety of camera placement settings and supports wireless IP control or the wired RS-422 protocol. 20x zoom allows you to hone in on precise locations while the HD lens with a maximum f/1.6 aperture and minimum 32.5mm (35mm equivalent) focal length provides room for wide views and low lighting conditions. A built-in neutral density filter and DRS (Dynamic Range Stretch) work in conjunction with 16-axis color correction to give you even more control of your resulting images.

Features:

• 3x 1/3" 2.2 MP U.L.T. MOS Sensors
• 20x Optical Zoom
• Dynamic Range Stretch for More Detail
• 1080/60i and 1080/60p
• Lightweight and Compact Design
• RS-422 Protocol Support

Specifications:

• Image Device: 1/3" progressive 2.2 MP 3MOS
• Lens: 20x zoom, f/1.6-3.4 4.5-90 mm (32.13-642.5 mm 35 mm equivalent)
• Built-in Filters: ND (CLEAR, 1/4, 1/16, 1/64)
• Minimum Focus Distance:
  • Entire range: 31.5" / 80 cm
  • Wide end: 15.75" / 40 cm
• Resolution: 1000 TVL
• Output Format:
  • NTSC: 1080/60i, 1080/60p, 720/60p, 480/60i, 480/60p
  • PAL: 1080/50i, 720/50p, 576/50p, 576/50i
• S/N Ratio: 60 dB
• Synchronizing System: Internal/external synchronization (BBS/3SY)
