GLP XDC1 IP Hybrid RGBL Wash White Strobe

The XDC1 offers impressive light output and color rendering quality based on the innovative color mixing of the X5 (RGB plus the special GLP Lime) in combination with two extremely powerful white strobe lines for all applications that require particularly powerful performance.

As with the fixtures in the new impression X5 series, the XDC1 features GLP’s proprietary iQ.Gamut color algorithm. This ensures optimum light output with excellent color rendering at any color temperature. It features a total of 18 wash LEDs, with 40W light output each, in three rows of pixels with 6 per row. The particularly narrow 10° optic ensures impressive mid-air effects, especially for applications at very long distances. The proven, extended color functions such as a referenced color wheel, color temperature control, color quality control with desaturation, magenta/green shift, etc. are also available in the XDC1. Thanks to the new tungsten channel, the weatherproof hybrid spotlight can also be used as a powerful audience blinder.

Features:

• Powerful diffuse double strobe line
• 10° washlight for long distances
• Excellent light quality based on X5 platform and iQ.Gamut technology
• Weatherproof according to IP65
• Vertical or horizontal alignment system

Specifications:

• Light Source:
  • Type: Strobe: white LED; wash: 40 W RGBL LED
  • Light Source: CountStrobe: 2×60; wash: 3×6
  • LED Refresh Rate: Optimal, high 1, high 2, max
  • CCT: Wash Default: 6,500 K; Optional: 8,000 K; 5,600 K; 4,200 K; 3,200 K
  • Duv: < +/- 0.01
  • TLCI: Wash: 90 @ 6,500 Kelvin; 75 @ 3,200 Kelvin
  • TM-30-15: Wash: 87/105 @ 6,500 Kelvin; 85/110 @ 3,200 Kelvin
• Optical System:
  • Output: Wash: 18,700 lm; strobe: 66,400 lm; strobe & wash: 85,100 lm
  • Beam Angle: Strobe: 140°/45° (field); wash: 10° (beam)
  • Beam Mode: 3.5°
• Effects:
  • Dimmer: 0: 100%; 16 bit
  • Color Mixing:
  • RGB
  • RGBL
  • x;y
• Color Mix Priority: Different layer priority settings
• CTC (Color Temperature Control): 2,500: 10,000 Kelvin
• CQC (Color Quality Control):
  • High Output (HO)
  • High Quality (HQ)
  • Desaturation
• Magenta/Green-Shift: Yes
• Tungsten Simulation: 8 Selectable curves
• Color Wheel: Virtual color wheel, 64 LEE referenced colors
• Pattern Effects: Wide range of static and dynamic pattern effects with XFade and transition
• Tilt Movement Angle: 180° (Manually)
• Flash Rate / Intensity Effects Speed:
  • Strobe to continuous open
  • Different intensity effect speeds
• Intensity Effects: Wide range of intensity effects
• Flash Duration:
  • Normal
  • Percentage
• Control
  • DMX Channels: M1: 21 / M2: 50 / M3: 58 / M4: 113 / M5: 80 / M6: 92 / M7: 53
  • Control Modes: 7
  • Protocol:
    • DMX (USITT DMX512-A)
    • RDM (ANSI/ESTA E1.20)
    • Art-Net
    • sACN
    • iQ.Mesh
    • Optional: Lumenradio CRMX @ FPO
  • Setting and Addressing:
    • Control panel with backlit graphic display
    • 4 button menu navigation
    • DMX
    • RDM
    • iQ.Service App
    • Internal Web interface
  • Software Update:
    • DMX link
    • via DProg
    • Internal Web interface
    • iQ.Mesh
    • Fixture2Fixture Push
  • High-Res Channels:
    • Dimming
    • Colormix
  • Power Modes:
    • Dynamic
    • Max strobe
    • Max wash
    • Balanced
  • Dimming Curves:
    • Linear
    • Soft
    • S-curve
  • Fan Modes:
    • Regulated
    • High
    • Medium
    • Low
    • Off
  • Subfixture Mode:
    • Normal
    • Independent
  • White Points: Wash default: 6,500 Kelvin; Optional: 8,000 Kelvin; 5,600 Kelvin; 4,200 Kelvin; 3,200 Kelvin
  • Others:
    • Stand Alone 1 captured scene
    • Art-Net/sACN Node
    • Data conversion
    • iQ.Mesh
    • FPO (flexible protocol option)
    • Internal web interface
    • SW Fixture2Fixture push
  • iQ.Gamut:
    • Full
    • Rec. 709
    • Rec. 2020
  • Flash Style:
    • Normal
    • Xenon
  • Duration Control:
    • Normal
    • Percentage
  • Signal:
    • Blackout
    • Hold
    • Houselight
    • Stand Alone Scene
    • Hibernation: Yes
• Connectors:
  • Power input:
    • Neutrik powerCON TRUE1
    • In/Out
• Electrical Specifications:
  • Power Input: 100: 240 VAC / 50: 60Hz
  • Power Supply: Auto-ranging electronic switch-mode
  • Fuse: T16A 250V 6x32mm
  • Max. Power (@230V): 1,100 W
• Thermal Specifications:
  • Cooling: Combined convection and forced air
  • Total Heat Dissipation (Calculated, +/-10%): 3,760 BTU/h
  • Temperature Range, Operating: 5 °C / 40 °F to 45 °C / 115 °F
• Mounting Options:
  • Mounting:
    • 1 pair of 1/4-turn locks
    • 4 hanging eyelets
    • 3x 13mm for rigging clamp
    • Eyelets for safety cable
    • Orientation: Any
  • Location:
    • Indoor Permanent
    • Outdoor Temporary
• Construction:
  • Housing Color: Black
  • Housing Material:
    • High-impact flame-retardant thermoplastic
    • Aluminum
    • Steel metal plates
  • Protection Rating: IP 65
  • Construction Features:
    • Alignment system
    • Threads for external accessory
    • Tiltable bracelet
    • Same vertical pixel pitch (wash)
• Dimensions & Weight:
  • Height: 14.21 in / 361 mm
  • Width: 15.75 in / 400 mm
  • Length: 8.12 in / 206.3 mm
  • Weight: 49.6 lbs. / 22.5 kg
