Description

Elation FUZE-WASH-500-WH 500 Watt Full Spectrum RGBMA LED Wash Moving Head Fixture - White

The Elation FUZE WASH 500 WH is a powerful automated LED Fresnel wash fixture perfect for theater, television, events, and precision lighting applications. Its high-CRI engine utilizes a 5-color homogenized LED array (Red, Green, Blue, Mint, and Amber), delivering exceptional color reproduction and up to 17,000 lumens of output. With features like virtual color temperature, Magenta/Green adjustments, CMY/RGB emulation, and a broad zoom range, the FUZE WASH 500 WH is ideal for applications that require vibrant colors and soft fields. It also offers an optional indexable ovalizer lens and an automated barn door system for enhanced beam control.

Features:

  • 500W Full Spectrum RGBMA LED Engine
  • Up to 17,000 Total Lumen Output @ 6500K
  • CRI up to 92.8
  • Wide Zoom Range from 6° to 53°
  • Variable 16-bit Dimming Curve Modes
  • CMY Emulation and Virtual Color Correction
  • Green/Magenta Shift
  • Virtual Gel Swatch Book

Specifications:

  • Source: 500W 6,500K RGBMA (Red, Green, Blue, Mint, Amber) LED Engine, 30,000 Hour Average LED Life
  • Photometric Data: 17,000 Lumen Fixture Output, CRI 92.8, Zoom Range 6° - 53°, Field Angle 12.1° - 63.6°, Beam Angle 6.3° - 53.7°
  • Effects: Motorized Zoom, Optional Indexable Ovalizer Lens, Optional Motorized Barn Doors, 16-bit Dimming, High-Speed Electronic Shutter & Strobe
  • Color: RGBMA Color Array, CMY/RGB Emulation, Variable CCT 2400K - 8500K, Green/Magenta Shift, Virtual Gel Swatch Book
  • Control/Connections: 6 DMX Channel Modes (RGBMA 21/30) (CMY 17/24) (RGB 20/26), 16-bit Pan/Tilt/Dimming, DMX Adjustable LED Frequency, DMX, RDM, E-FLY Wireless, Art-Net, sACN Support, 4 Button Touch Control Panel, Full Color 180° Reversible LCD Menu Display, Locking 5pin XLR In/Out, Locking RJ45 Ethernet In/Out, Locking IP65 Power In/Out, USB Connection (Firmware Updates)
  • Size/Weight: Length: 16.06" (408mm), Width: 10.07" (256mm), Height: 21.7" (550mm), Weight: 40.8 lbs. (18.5kg)
  • Electrical/Thermal: AC 100-240V - 50/60Hz, Max Power Consumption 609W, Operating Temp: 14°F to 113°F (-10°C to 45°C), BTU/hr: 2151.71
  • Approvals/Ratings: CE, cETLus, IP20, FCC
