X-Laser Defiant Spark 3W Sapphire HP Class 4 Laser
The Defiant Spark is X-Laser's answer to the frustrated production customers that have been asking for a compact, scanning laser system that cools properly and is reliable on the road. Built to thrive almost anywhere, the Defiant Spark delivers Defiant quality, high power, single color effects, precise graphics scanners and more, all from a chassis with a footprint slightly larger than a smartphone.
Multiple color and power optionsDefiant Spark is built with LASORB protected all-diode construction for maximum reliability. Choose from power ranges of up to 3W of laser power in red, green, or blue.
All-New GraphiX Scanning SystemX-Laser's Graphix laser scanning system, developed in partnership with Pangolin Laser Systems, utilizes their new 506 scanners and custom designed electronics to unlock new design possibilities.
Features:- Spark 1W Sapphire Class 4 Laser (High-Powered model)
- High powered, ultra-compact, Class 4 laser system
- Multiple power configurations up to 3W of red, green, or blue
- LASORB protected all diode laser system
- Fanless, water resistant IP55 design
- All new 30K GraphiX Scanning system
- 63% smaller than competing ultra-compact systems
- Control via ILDA, with linkable ILDA in/out
- P67 locking power supply
- RJ45 in/out e-stop ready
- Rugged type II anodized aluminum housing
- Housing available in any Pantone color
- X-Laser no-hassle 2 year warranty on hardware, 1 year on laser source
- Includes User Training DVD, User Manual, IEC cord, Warranty Information, Beam Blocks, and Beam Block Foil
- Laser Variance Required for operation. Apply hassle free with an EZ Variance Kit
- Control: ILDA
- Scanners: 30k @ 8 degrees, 4mm standard
- Color Modulation: 50khz analog
- Laser Energy: 700mJ to 3J CW
- FDA/IEC Class: Class 4
- Cooling: Passive, fanless heatsink
- Physical: 6" x 4.5" 3.5", 2.2lbs.
- Housing Type: Anodized Type II Aluminum
- Power Supply: Locking IP67 to grounded Edison
- Power: 110-230V, 50-60Hz, 50W typical
- Beam Divergence: 1.5-3mRad
- Beam Source: Direct Diode 450-638nm
