Vari-Lite VL2500 Wash Moving Head 2-Pack with Case
Package includes:
- 2x Vari-Lite VL2500W Wash Moving Head Fixtures
- 1x Road Case with Caster Wheels
The VL2500 Wash luminaire is equipped with the same features and characteristics that make the original Series 2000 fixtures so useful. It is still small, lightweight, and fast with a 700-watt short-arc lamp, impressive lumen output, and a zoom range from 14º to 55.5º. Of course, the VL2500 Wash luminaire still provides three-wheel CYM color mixing. When combined with 11 standard colors on a fixed wheel, the color options are practically limitless. The new features in this luminaire are the coated glass dimmer wheel which provides smooth fades, and a separate dual-blade strobe system that offers quiet and reliable strobe effects. In addition, the VL2500 Wash luminaire’s pan and tilt motors are now more powerful and provide more torque. The fixture is the same size at the VL2500 Spot luminaire, and it has the same profile, providing a consistent hang configuration and appearance no matter which luminaire type is required. The VL2500 Wash luminaire can be controlled from virtually any DMX512 console or DMX512 output device.
Specifications:
- Programmable Functions
- Color System: A three-filter CYM cross-fading mechanism. A fixed color wheel with 11 interchangeable
- color filters and one open space capable of continuous rotation for additional effects.
- Zoom Optics: Continuously variable field angle from 14° to 55.5°.
- Beam Size Control: A zoomable beam spreader mechanism provides continuous beam size control for both rapid changes and smooth timed beam angle adjustments.
- Intensity Control: A coated glass dimmer wheel provides full field dimming designed for smooth timed fades.
- Strobe: A high-performance dual blade strobe system capable of ultra-fast operation
- Pan and Tilt: Smooth, time-controlled continuous motion by way of three-phase stepper motor systems.
- Range: Pan - 540°, Tilt - 270°.
- Accuracy: 0.3° resolution.
- Description
- Source: 700W Short Arc Lamp
- Color Temperature: 5600K
- CRI: 80
- Fixture Output: 14,700 lumens.
- Power Requirements: Standard AC power distribution from 90– 264 VAC, 50/60 HZ. The unit requires 4 to 12 A depending on the AC supply voltage.
- Reflector: Precision glass reflector system with dichroic cold mirror coating.
- Operational Temperature: -20° to 122°F (-29° to 50°C). Note: Derate to 113°F (45°C) for operation below 100 VAC.
- Cooling: Forced air cooling.
- Control: Completely compatible with a wide variety of DMX512 consoles.
- DMX Channels: 15
- Mounting Position: The VL2500 Wash luminaire can be mounted and operated in any orientation.
- Spacing: Hangs on 19 in. (48.3 cm) centers.
- Weight: 57.3 lbs (26.1 kg).
- Color System: A three-filter CYM cross-fading mechanism. A fixed color wheel with 11 interchangeable
- color filters and one open space capable of continuous rotation for additional effects.
- Zoom Optics: Continuously variable field angle from 14° to 55.5°.
- Beam Size Control: A zoomable beam spreader mechanism provides continuous beam size control for both rapid changes and smooth timed beam angle adjustments.
- Intensity Control: A coated glass dimmer wheel provides full field dimming designed for smooth timed fades.
- Strobe: A high-performance dual blade strobe system capable of ultra-fast operation
- Pan and Tilt: Smooth, time-controlled continuous motion by way of three-phase stepper motor systems.
- Range: Pan - 540°, Tilt - 270°.
- Accuracy: 0.3° resolution.
- Source: 700W Short Arc Lamp
- Color Temperature: 5600K
- CRI: 80
- Fixture Output: 14,700 lumens.
- Power Requirements: Standard AC power distribution from 90– 264 VAC, 50/60 HZ. The unit requires 4 to 12 A depending on the AC supply voltage.
- Reflector: Precision glass reflector system with dichroic cold mirror coating.
- Operational Temperature: -20° to 122°F (-29° to 50°C). Note: Derate to 113°F (45°C) for operation below 100 VAC.
- Cooling: Forced air cooling.
- Control: Completely compatible with a wide variety of DMX512 consoles.
- DMX Channels: 15
- Mounting Position: The VL2500 Wash luminaire can be mounted and operated in any orientation.
- Spacing: Hangs on 19 in. (48.3 cm) centers.
- Weight: 57.3 lbs (26.1 kg).
