Vari-Lite 74817-051 VL3600 LT PROFILE IP 1000 Watt Monochromatic Light Engine with 2-Pack Rails / DMX Tails

The Vari-Lite VL3600 LT Profile IP is a high output, long-throw production profile fixture designed at the forefront of optical technology to provide superior output in extremely narrow zoom ranges. With a 1000W monochromatic light engine and IP65 outdoor rating, the VL3600 LT’s huge output power is ready to light the show from any distance in any weather. For a consistent experience, the VL3600 LT Profile IP offers long-throw key and effect lighting with the same size, speed, and industry standard features as the VL3600 Profile IP.

Features:

  • Long throw production profile luminaire with high levels of illumination (>50,000 Lux @ 10m / 4722fc @ 32ft.) – high-output key lighting in the largest of venues.
  • Optimized long throw optical system offering a 3° to 42° zoom range – tailored zoom for key lighting at distance.
  • Large 220mm front lens and matched feature set to the industry-leading VL3600 Profile IP – long-distance key lighting or high-impact effect lighting with consistent look and feel.
  • IP65 outdoor rating – outstanding performance no matter the weather.
  • CMY+CTO graduated color wheel mixing system – Provides a wide color mixing spectrum with a homogenization of color that completely fills the front lens at all times, improving direct view applications on stage or on camera.
  • Color quality enhancement control – dedicated color enhancement wheel, which include CRI boost filter and a selection of minus green.
  • Touring and Installations versions available. – Touring version with chassis mounted IP65 Power and DMX connectors. Installation version fitted with IP65 inline connectors.
  • Exclusive VL*FX animation wheel system – Give users access to 3 different animation effects wheels that can create dynamic projected and mid-air effects on their own or layered with gobos and prisms.
  • V*Track Calibration* System – Size and power with none of the unwanted movement. Limit movement during calibration and reduce start up time. Reduce risk of the fixture hitting set objects or shaking the rig.
  • Wireless DMX using Lumen Radio CRMX TimoTwo™ – cable-free connection of your DMX / RDM data to the fixture fitted as standard. Dynamic wireless system that ensures an improved cognitive coexistence across wireless networks.
  • Full set of fixture features to meet the needs of the most demanding show – Two Gobo wheels with interchanging gobos, four blade full wipe framing system with 120° of rotation, Iris and dual prism system which includes both an effects and scenic prism.

Specifications:

  • Source:
    • LED System: Monochromatic Light Engine
    • Max Power Consumption: 1000 W
    • Lumens: 85,000
    • CCT: 7500 K
    • LED Refresh Rate: 500Hz to 25KHz
    • Dimming: Electronic 16-bit
    • Dimmer Curves: Square Law (Default), Linear, S-Curve
    • Dimmer Control Option: Dimmer Snap On/Off (reduces auto dimmer smoothing)
    • Strobe Speed: 0 - 30Hz
    • Strobe Modes: Continuous, Random, Random Sync
  • Optical Performance:
    • Subtractive Color Mixing: CMY Graduated Glass Wheels
    • Color Mixing Control: CMY 8-bit
    • Color Snap On/Off: Faster color changes with reduced smoothing
    • Variable CTO: 7200 to 3200 K
    • Fixed Color Wheel: 6 Colors + Open, 4 Color corrections + Open
    • Color Wheel Effects: Split Colors, Color Wheel Spin, and Shake
  • Electrical:
    • Max Output Power Consumption: 1475 W
    • Power Connection: TrueOne Compatible Input
    • Input Voltage: 120-240 VAC, 50 / 60 Hz
  • Data:
    • Supported Protocols: DMX Modes, 16-Bit Enhanced, 16-Bit
    • Data Connections: 5-pin XLR, RJ45, Wireless DMX (Lumen Radio), USB
    • FollowSpot Mode
  • Cooling System:
    • Fan Mode: Standard, Studio, Whisper
    • Cooling System: Hybrid sealed liquid and forced air system
  • Mounting:
    • Hanging Type: 2 x VL Hook Rails L
    • Hanging Centers: 700.0 mm (30.0 in)
    • Mounting/Hanging Orientation: Hanging, Floor, Side
    • Secondary Safety Wire Point: 1x Safety point on underside of upper enclosure
  • Photometrics and IES Files:
    • 3° Beam @ 5m / 16.4 ft: 203,300 lux (18,887 fc)
    • 3° Beam @ 10m / 32.8 ft: 50,825 lux (4,722 fc)
    • 42° Beam @ 5m / 16.4 ft: 4,138 lux (384 fc)
    • 42° Beam @ 10m / 32.8 ft: 1,035 lux (96 fc)
  • Color System:
    • Subtractive Color Mixing: CMY Graduated Glass Wheels
    • Color Mixing Control: CMY 8-bit
    • Color Snap On/Off: Faster color changes with reduced smoothing
    • Variable CTO: 7200 to 3200 K
    • Fixed Color Wheel: 6 Colors + Open
    • Fixed Color Wheel: 4 Color corrections + Open
    • Color Wheel Effects: Split Colors, Color Wheel Spin, and Shake
  • Noise Level / Fan Control:
    • Fan Mode: Continuous (On) / Auto Ramping
    • Fan Level Preset: Standard, Studio, Whisper
    • Cooling System Type: Hybrid sealed liquid and forced air system
  • Imaging:
    • Framing Shutters: 4 Blade - Full Wipe, +/-60° rotation
    • Effects Prism: 3 Facet Round
    • Scenic Prism: 4 Facet Linear
    • Prism Features: Index/Rotation, MegaStep, Dual Overlay
    • Beam Softening: Variable control - Light Frost
    • Beam Softening: Variable control - Medium Frost
    • Iris: 16 leaf iris open to 80% closing, Iris pulse effect
  • Movement:
    • Pan Angle: 540°
    • Pan Speed: 4.54 s
    • Tilt Angle: 260°
    • Tilt Speed: 3.50 s
    • Calibration System: V*Track Calibration
