TC Electronic 6000MKII Stereo Multi Effects Processor

TC Electronic 6000MKII Stereo Multi Effects Processor

Must be bought with 1 Icon CPU and 1 Icon Controller

The TC Electronic Music 6000 MkII is a DSP system optimised for all music production requirements, and includes stereo and multi-channel Reverb algorithms, Stereo Mastering tools, LM Loudness Radar meter and the George Massenburg Labs MDW EQ. The TC Electronic Music 6000 MkII includes the complete Halls of Fame and Skywalker Sound Collection reverb and delay presets. It further includes VSS3, VSS4, NonLIn2 and Reflector reverbs. The Music 6000 MkII is also offered with the Icon remote.

Features:

• Comprehensive mastering-grade processing unit for music production
• Comes complete with pre-installed set of the tools most relevant for music production
• Heavily tested in the most demanding production environments since 1999
• Used by thousands of leading studios around the globe
• Includes all the multi-channel reverb algorithms from the legendary REVERB 6000
• Includes VSS3 and 4, Nonlin2, and Reflector, plus access to hundreds of film and music presets
• Exceptional stereo mastering tools for multiband compression, EQ, expanding, normalizing, and Brickwall Limiting let you achieve a flawless sound
• Eight-channel Matrix 88 mixer gives you intelligent limiting, 48-bit digital summing, accurate delays, and bit pattern transparency, turning your unit into a top-of-the-line mixer
• Detailed LM6 loudness radar meter
• Additional utilities included for unparalleled HiRES EQ, unobtrusive pitch control, and surround production support
• Expandable with a large range of optional algorithm tools to further customize your setup to your unique production requirements
• SYSTEM 6000 INTEGRATOR AAX*, AU* and VST* remote control plug-in for DAW and NLE integration
• ICON remote hardware not included

Specifications:

• Digital Inputs and Outputs:
  • Connectors: SUB-D, 25 pole (8 channels AES/EBU in/out)
  • Formats: AES/EBU (24 bit)
  • Internal sample rate: 96 kHz, 88.2 kHz, 48.0 kHz, 44.1 kHz
  • Internal clock precision: +/- 30 ppm
  • Jitter rejection at external sample rates: 30 to 34 kHz, 42.5 to 45.5 kHz, 46.5 to 48.5 kHz, 85 to 91 kHz and 93 to 97 kHz.
  • Rejection filter (4'th order): < -3 dB @ 50 Hz, < -65 dB @ 500 Hz, < -100 dB @ 1.4 kHz
  • Rejection filter peak (jitter gain): < 1 dB @ 2 Hz
  • Intrinsic interface jitter: < 1 ns peak, BW : 700 Hz to 100 kHz
  • Digital output phase: < 3 % of sample period
  • Output Dither: HPF/TPDF dither 8-24 bit mono
  • Processing Delay: 0.15 ms + 0.21 ms per engine @ 48 kHz, 0.07 ms + 0.1 ms per engine @ 96 kHz
  • Frequency Response DIO: DC to 23.9 kHz ± 0.01 dB @ 48 kHz, DC to 47.9 kHz ± 0.01 dB @ 96 kHz
• General:
  • Finish: Natual color anodized aluminum face plate. Painted and plated steel chassis
  • Dimensions: 19 x 3.5 x 12 inches (483 x 89 x 305 mm)
  • Weight: 19 lbs. (8,6 kg)
  • Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
  • Power Consumption: 45 watts
  • Backup Battery Life: >10 years
