Shure MXCWNCS-BR 10-Bay Networked Charging Station for SB930 Batteries - Brazil Power Supply
The MXCWNCS Networked Charging Station charges 10 SB930 batteries in 4 hours. LED indicators display charge status, and a RJ-45 Ethernet connection enables battery levels to be monitored remotely. Includes IEC power cable and mounting hardware for wall or rack mounting.
Features:
- Accommodates up to 10 SB930 rechargeable batteries
- 5-segment LEDs on the unit display charge status individually for every battery
- RJ45 Ethernet connection enables remote monitoring of battery charge status in hours and minutes via Microflex Complete Wireless graphical user interface
- Charges 10 batteries to 50% charge in 1.5 hours, 100% charge in 4 hours
- Selectable storage mode partially discharges batteries for long-term storage or shipment
- Includes hardware for wall and rack mounting
- Includes power cable
Specifications:
- Network:
- Interface: Ethernet
- Link Speed: 10/100Mbps
- Networking Addressing Capability: DHCP or Manual IP address
- Cable Length: 100m (max)
- Cable Type: > Cat5e (shielded/unshielded)
- Connector Type: 1 x RJ45
- Connector LED: Status (Green) / Link Speed (Amber)
- User Interface:
- Display Type:
- 5 LEDs per bay for charging indication
- 1 status LED
- 2 Ethernet LEDs
- Mechanical:
- Dimensions: 72.4mm x 438.9mm x 193.5mm (2.9" x 17.3" x 7.6")
- Weight: 2825 g
- Color: Black
- Material: Molded Plastic, Steel
- Mounting Type: Tabletop, wall mount or rack (4U rackspace required)
- Environmental:
- Operating/Discharging Temperature Range: -20°C (-4°F) to 35°C (95°F) Discharging may occur when storage mode is enabled
- Charging Temperature Range: 0°C (32°F) to 35°C (95°F)
- Storage Temperature Range: -29°C (-20.2°F) to 60°C (140°F)
- Relative Humidity: <95%
- Network:
- Interface: Ethernet
- Link Speed: 10/100Mbps
- Networking Addressing Capability: DHCP or Manual IP address
- Cable Length: 100m (max)
- Cable Type: > Cat5e (shielded/unshielded)
- Connector Type: 1 x RJ45
- Connector LED: Status (Green) / Link Speed (Amber)
- User Interface:
- Display Type:
- 5 LEDs per bay for charging indication
- 1 status LED
- 2 Ethernet LEDs
- Display Type:
- Mechanical:
- Dimensions: 72.4mm x 438.9mm x 193.5mm (2.9" x 17.3" x 7.6")
- Weight: 2825 g
- Color: Black
- Material: Molded Plastic, Steel
- Mounting Type: Tabletop, wall mount or rack (4U rackspace required)
- Environmental:
- Operating/Discharging Temperature Range: -20°C (-4°F) to 35°C (95°F) Discharging may occur when storage mode is enabled
- Charging Temperature Range: 0°C (32°F) to 35°C (95°F)
- Storage Temperature Range: -29°C (-20.2°F) to 60°C (140°F)
- Relative Humidity: <95%
