Sennheiser MAS 133 Microphone Control Box
The MAS 133 is a versatile XLR inline switch box for integrated microphone solutions. Attached between the mic and mixing console, it powers the MAS 1 microphone button. It is able to control any XLR-attached microphone using switchable microphone activation modes (PTT, PTM, toggle ON/off, permanent on). Furthermore, the MAS 133 features a TTL logic, enabling the user to trigger e.g. camera or media control systems for various purposes.
Features:
- Powers the MAS1 mic button
- Easy microphone activation
- Switchable microphone modes
- TTL logic out for media/camera control
- Made in Germany
- Programmable Microphone Modes:
- On
- On/Off
- Push to talk
- Push to mute
Specifications:
- Dimensions (HxWxD): 1.7" x 5.9" x 1.7"
- Connector:
- Mic in: XLR-3F
- Mic out: XLR-3M Pin assignment: 1 = Ground, 2 = Positive (+), 3 = Negative (-)
- Switch in: XLR-5F Pin assignment: 1 = Ground, 2 = Switch, 3 = LED Red (-), 4 = LED Green (-), 5 = LEDs + 12 V out
- Weight: 7.47oz
- Operating temperature: 14°F to 122°F
- Current consumption: 4.5mA
- Output voltage:
- High level: output voltage > 2.4V
- Low level: output voltage < 0.4V
