Description
RGBAW+UV IP65 LED Par Can
The new IP65 rated SIXPAR 300IP™ features (18) 12W 6-IN-1 RGBAW+UV LEDs, 100,000 average hour LED life, 15° beam and 25° field angles, electronic strobe and dimming (0-100%), 5 variable dimming curve modes, dual yoke / floor stand, multiple unit power linking, RDM (remote device management), rugged die-cast aluminum exterior, flicker free operation for TV and FILM, 220W max power consumption, and a multi-voltage universal auto switching power supply (110-250v).
Features:
- IP65 Rated Outdoor Par Up Light
- (18) 12W 6-in-1 RGBAW+UV LEDs
- 100,000 Average Hour LED Life
- 15° Beam and 25° Field Angles
- 5 Variable Dimming Curve Modes
- Dual Yoke / Floor Stand
- Multiple Unit Power Linking
- RDM - Remote Device Management
- Rugged Die-Cast Aluminum Exterior
- Flicker Free Operation for TV and FILM
Specifications:
- Source:
- (18) 12W 6-in-1 RGBAW+UV LEDs
- 100,000 Hour Average LED Life
- PHOTOMETRIC DATA
- 24,500 LUX 2,276 FC @3.3’ (1m) (15° Full ON)
- 8,500 LUX 790 FC @6.6’ (2m) (15° Full ON)
- 3,950 LUX 367 FC @9.8’ (3m) (15° Full ON)
- 2,150 LUX 200 FC @13.1’ (4m) (15° Full ON)
- 1,350 LUX 125 FC @16.5’ (5m) (15° Full ON)
- Effects:
- Electronic Strobe
- Color and Chase Macros
- Electronic Dimming: 0% - 100%
- 5 Variable Dimming Curve Modes
- Control / Connections:
- (4) DMX Channel Modes (6 / 7 / 8 / 12)
- (4) Button Touch Control Panel
- LCD Menu Display
- IP DMX In/Out
- IP Power In/Out
- Size / Weight:
- Length: 14.4” (365mm)
- Width: 4.9” (125mm)
- Vertical Height: 14.4” (365mm)
- Weight: 21.0 lbs. (9.5 kg)
- Electrical / Thermal:
- AC 110-250V - 50/60Hz
- 220W Max Power Consumption
- Power Linking: 5pcs @110V / 10pcs @240V
- 5°F to 113°F (-15°C to 45°C)
- Approval / Ratings:
- Installation:
- Rigging: Integrated Dual Yoke / Floor Stand
- Working Position: Any (360°)
