RCF MR 52EN W 2 Way Bass Reflex Wall Mount Cabinet, 30W - White - Trasf/Low Imp

RCF MR 52EN W 2 Way Bass Reflex Wall Mount Cabinet, 30W - White - Trasf/Low Imp

Write a review

SKU: MR 52EN W

$379.00
$379.00
Sale Sold out
Shipping calculated at checkout.

Available options

View full details

Description

2 Way Bass Reflex Wall Mount Cabinet, 30W - White - Trasf/Low Imp

MR 52EN is a compact two-way speaker ideal for both alarm messages broadcasting and business music systems. The installation is fast and efficient using the adjustable mounting bracket (included). The enclosure is made of high-density ABS and includes a protective steel grille and connection cover. The terminal connection blocks, for input and output flameproof cables, are made of ceramic material. A thermal fuse protects the integrity of the line in case of heat affecting the speaker. Power selectable with dedicated switch.

Features

  • 5" woofer with 1" dome tweeter
  • Power selectable (100 V): 30 W – 15 W – 7.5 W – 3.75 W
  • 89 dB sensitivity
  • Colour white RAL 9016
  • Flameproof ABS body, steel grille
  • In/out ceramic terminal block
  • Thermal fuse protection

    • Specifications

    Acoustical specifications
    Frequency Response (-10dB) 80 Hz - 20000 Hz
    Max SPL @ 1m 103 dB
    Max SPL @ 4m 91 dB
    Coverage angle 180°
    System Sensitivity 89 dB
    System Sensitivity 1W @ 4m 77 dB
    Power section
    Power Handling 30 W
    Peak Power Handling 120 W PEAK
    Protections Thermal fuse
    Recommended Amplifiers DXT 3000, DXT 4000, DXT 7000
    Transducers
    Dome Tweeter 1 x 1.0''
    Woofer 1 x 5.0''
    Input/Output section
    Input connectors Ceramic screw terminals
    Output connectors Ceramic screw terminals
    Constant Voltage Transformer 100 V
    Power selection 1 30 W - 333 ohm
    Power selection 2 15 W - 667 ohm
    Power selection 3 7.5 W - 1333 ohm
    Power selection 4 3.75 W - 2667 ohm
    Standard compliance
    Safety agency CE compliant
    EN54-24 certified Yes
    CPR number 1488-CPR-0591/W
    Physical specifications
    Cabinet/Case Material ABS
    Grille Steel
    Color White - RAL 9016, Black - RAL 9005
    Size / Weight
    Height 242 mm / 9.53 inches
    Width 192 mm / 7.56 inches
    Depth 190 mm / 7.48 inches
    Weight 3 kg / 6.61 lbs
    Shipping information
    Package Height 300 mm / 11.81 inches
    Package Width 310 mm / 12.2 inches
    Package Depth 200 mm / 7.87 inches
    Package Weight 3.5 kg / 7.72 lbs
