Description
Passive Compact Horn 20W - 8 Ohm
Extremely compact horn speaker with high acoustic output. The HD 1110 is particularly suitable for use in call or alarm systems in places with a high level of background noise. Fully protected against atmospheric agents, it can also be used outdoors.
FEATURES
- Plastic body, GREY RAL 7035
- Solid and compact construction
- Mounting bracket included
- Driver impedance 8 Ohm
Specifications
ACOUSTICAL SPECIFICATIONS
-
Frequency Response (-10dB): 900 Hz - 13000 Hz
-
Max SPL @ 1m: 114 dB
-
Coverage angle: 175°
-
System Sensitivity: 101 dB
POWER SECTION
-
Nominal Impedance: 8 ohm
-
Power Handling: 20 W
-
Peak Power Handling: 80 W PEAK
TRANSDUCERS
-
Compression Driver: 1 x 1.5''
INPUT/OUTPUT SECTION
-
Input connectors: Cable
-
Output connectors: Cable
STANDARD COMPLIANCE
-
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
-
Cabinet/Case Material: Plastic
-
Hardware: U bracket
SIZE / WEIGHT
-
Depth: 93 mm / 3.66 inches
-
Diameter: 100 mm / 3.94 inches
-
Weight: 0.42 kg / 0.93 lbs
SHIPPING INFORMATION
-
Package Height: 100 mm / 3.94 inches
-
Package Width: 120 mm / 4.72 inches
-
Package Depth: 120 mm / 4.72 inches
-
Package Weight: 1.2 kg / 2.65 lbs
