L-Acoustics 8XT Loudspeaker
Speaker operates on a frequency bandwidth of 65Hz to 20kHz. This response can be lowered to 32Hz with the addition of the SB18 subwoofer. It contains a 1.5-inch diaphragm compression driver coaxially-loaded by an 8-inch low frequency transducer mounted in a bass-reflex tuned enclosure. The internal passive crossover network uses proprietary third order filters. The linearization and protection of the transducers is defined by the drive parameters contained in the amplified controllers.
Specifications:
- Usable bandwidth (-10dB): 65 Hz - 20 kHz ((8XT_FR)preset)
- Nominal directivity (-6dB): 100° Axi-symmetric
- Maximum SPL: 127 dB ((8XT_FI) preset)
- RMS handling capacity: 280 W ((8XT_FI) preset)
- Components:
- LF: 1 x 8’’ weather-resistant transducer
- HF: 1 x 1.5’’ diaphragm compression driver
- Nominal impedance: 8 ohms
- Physical data:
- H x W x D: 422 x 250 x 271 mm - 16.6 x 9.8 x 10.7 in.
- Wedge angle: 30° ou 40° from vertical
- Weight (net): 11 kg - 24.3 lbs.
- Connectors: 2 x 4-point Speakon®
- Material: 15 and 18 mm Baltic birch plywood
- Finish: Grey-brown RAL 8019®
- Front: polyester-powder coated steel grill, acoustically transparent Airnet® cloth
- Rigging: integrated handles and pole mount socket, Omnimount® compatibility, and optional ETR8-2 bracket
- LF: 1 x 8’’ weather-resistant transducer
- HF: 1 x 1.5’’ diaphragm compression driver
- Nominal impedance: 8 ohms
- H x W x D: 422 x 250 x 271 mm - 16.6 x 9.8 x 10.7 in.
- Wedge angle: 30° ou 40° from vertical
- Weight (net): 11 kg - 24.3 lbs.
- Connectors: 2 x 4-point Speakon®
- Material: 15 and 18 mm Baltic birch plywood
- Finish: Grey-brown RAL 8019®
- Front: polyester-powder coated steel grill, acoustically transparent Airnet® cloth
- Rigging: integrated handles and pole mount socket, Omnimount® compatibility, and optional ETR8-2 bracket
