HK Audio Linear 7 115 FA Active Full-Range 2000 Watt 15 Inch Speaker
The LINEAR 7 115 FA active and network-compatible full-range speaker delivers more sound pressure in the low-frequency range thanks to its larger cabinet volume. With the Bass Boost preset optimised for each speaker, the low-frequency range can be boosted as required.
Features:
- 2000W Class-D Amplifier
- 15" Woofer + 1" High-Frequency Driver
- 57 Hz to 19 kHz Frequency Response
- 134 dB Max SPL, 60 x 40° Dispersion
- DSP Platform with Modern Network Tech
- 10-Band Parametric EQ, Delay & Limiting
- Selectable Presets, High-Res AD/DA, FIR
- Combo XLR-1/4" Input, XLR Thru + DSP Out
- DuoTilt Pole Cup: 3/7°
Specifications:
- Max. SPL @ 10% THD: 129 dB half space (70 Hz – 12 kHz averaged)
- Max. SPL peak @ 10 % THD: 134 dB half space
- Frequency response +/-3 dB: 57 Hz – 19 kHz
- Frequency response -10 dB: 54 Hz – 20 kHz
- Power amp output (peak power): 2000 W
- Amp type: Class D - biamped
- Low-/mid speaker: 1x 15", 3" voice coil
- HF driver: 1", 1.7" voice coil
- Horn directivity: 60° x 40° CD horn, rotatable
- Active crossover frequency: 1.5 kHz FIR X-over with 60 dB/oct.
- Maximum input level: +20 dBu
- Analog inputs: 1x XLR combo balanced
- Analog thru: 1x XLR balanced
- DSP Out: 1x XLR
- Network port: Ethercon RJ45, 1x In, 1x Thru
- Filter presets: Flat, Boost, Low Cut, Remote
- Remote software: DSP CONTROL (Windows, Mac OS)
- DSP functions: Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
- Sample rate: 96 kHz
- System latency: Less than 2.6 ms
- Mains connector: 1x Powercon NAC3 In, 100–240 V
- Power consumption: 1 A / 100–240 V nominal according to EN 62368-1
- Clustering angle: 60°
- Pole mount: DuoTilt 3°/7°
- Rigging points: 4x M8 (AP-8)
- Carrying handles: 2x MultiGrip
- Housing: Hybrid (birch multiplex/MDF)
- Finish: Black acrylic enamel
- Front grille: 2 mm metal grille backed with black acoustic foam
- Dimensions (WxHxD): 45 x 71 x 45 cm 17-23/32 x 27-61/64 x 17-23/32"
- Weight: 32 kg / 70.5 lbs
