ETC Source 4WRD PAR Fixture Body - Silver
The Source 4WRD II PAR Fixture Body allow you to transform your Source 4WRD II LED into a beautiful softlight. Taking advantage of the great energy efficiency, cool operating temperatures, DMX dimming or line voltage dimming and no lamp changes, the Source 4WRD PAR delivers an amazing output without compromise.
Features:
- Fixture bodies for use with Source 4WRD II LED
- Works just like a Source Four PAR, using the same accessories
- 155 W at full output
- Brighter than the 750 W HPL versions
- Uses same Source 4WRD II LED as the Source 4WRD II ellipsoidal
Specifications:
- Source:
- LED details: S4WRD LED (48 Cree LEDs) *Not Included*
- Max lumens: 10,569 (PAR)
- Lumens per watt: 68 (PAR)
- L70 rating (hours to 70% output): 45,000 hours (LM84 test pending)
- Notes: S4WRD LED sold separately
- Color:
- Colors used: Warm or Cool White
- Color temperature range: 3200 K 80 or 90+ CRI, 5900 K 90+ CRI
- Calibrated array: No
- Red shift: No
- Notes: S4WRD is available in 80+ CRI (Standard) and 90+ CRI (Gallery)
- Optical:
- Beam angle range-PAR: 19.5°–62°
- Gate size: N/A
- Aperture size: 7 in
- Pattern projection: No
- Pattern size: N/A
- Camera flicker control/Hz range: No
- Notes: PAR ships with an AR coated flat lens. Additional PAR lenses sold separately.
- Control:
- Input method: DMX Control or Line Dimmed
- Protocols: DMX / RDM via RJ45
- Modes (Footprint): 1 Channel (Intensity) for DMX
- RDM configuration: Yes
- UI type: 7-segment address display, local level control via UI
- Local control: Yes
- Onboard presets: No
- Onboard sequences: No
- Onboard effects: No
- Fixture to fixture control: No
- Electrical:
- Voltage range: 209–252 V, 50 Hz (230 V)
- Input method: Hard-wired, 1 m cord, bare end (230 V)
- Inrush: 12 A (first half-cycle) at 230 V
- Fixtures per circuit: 6 fixtures per non-dimmed circuit (ER15AFR module)
- Wattage (Typical/Standby): 175 W / 3.7 W (230 V)
- Current draw: 0.75 A at 230 V
- Notes: When using line dimming, see the S4WRD Manual for dimmer setup When using line dimming, standby power is 0 W
- Thermal:
- Ambient operating temp: 5°–50° C (41°–122° F)
- Fan (controllable): Yes (no)
- Droop compensation: No
- dB range: 28 dBa average at 1 m
- BTUs/hour: 529
- Physical:
- Materials: Die-cast aluminum
- Color options: Silver
- Mounting options: Yoke
- IP rating: IP-20
- Weight: PAR: 3.0 kg (6.6 lb)
- Included accessories: Color frame
- Notes: Includes S4WRD mounting post. Required S4WRD LED available separately
- Warranty:
- Fixture body: 5 years
- LED array: 10 years
