ETC ColorSource Spot V Light Engine with Multiverse / 15-30 Degree Zoom Lens Tube - Black
The ETC ColorSource Spot V combines affordability with high-quality color output and brightness. Equipped with a five-color LED array (red, green, blue, indigo, and lime), it can create a versatile range of colors from soft pastels to bold tones. This fixture features Multiverse wireless DMX/RDM control, NFC configuration, and an easy-to-use interface, making it ideal for diverse lighting applications. With durable construction and the ability to adapt with accessories, it’s perfect for both theatrical and studio use.
Features:
- Five-color array with red, green, blue, indigo, and lime LEDs
- Simple user interface with seven-segment display
- Powercon True1 top connector for easy power connection
- DMX/RDM in and thru (5-pin XLR) with Multiverse wireless DMX/RDM support
- NFC (near field communication) configuration for quick setup
- LED droop compensation for consistent brightness
- Tour-ready aluminum housing
- Compatible with adapters for Fresnel or CYC lighting configurations
Specifications:
- Source:
- LED: 60 Lumileds LUXEON® C and LUXEON Rebel LEDs
- Max Lumens: 9,498
- Lumens per Watt: 48
- L70 Rating (hours to 70% output): 54,000 hours
- Color:
- Colors Used: Red, green, blue, indigo, lime
- Calibrated Array: Yes
- Optical:
- Beam Angle Range: Swappable lens tubes, 15-30 degree included
- Gate Size: 80 mm
- Aperture Size: 6.25" – 14" (depending on lens tube)
- Control:
- Input Method: DMX512 via 5-pin XLR connector
- Protocols: DMX512/RDM
- User Interface: Seven-segment, three-button interface
- Wireless:
- Band: 2.400–2.480 GHz
- Range: 100 m indoors, 500 m line of sight
- Broadcast Power: 100 mW
- Electrical:
- Voltage Range: 100–240 VAC, 50/60 Hz
- Input Method: powerCON TRUE1 TOP power in and thru
- Thermal:
- Ambient Operating Temp: 32° – 104° F (0° – 40° C)
- Droop Compensation: Yes
- Noise Level: 24.4 dBA average at 1 m
- Physical:
- IP Rating: IP20
- Color: Black
- Weight: 17 lb (7.7 kg)
