EPSON V11HA08620 PowerLite 755F Projector

EPSON V11HA08620 PowerLite 755F Projector

Customize and display unique digital signage with this versatile ultra short throw projector.

Bring captivating, custom digital signage to nearly any location with the sleek PowerLite 755F ultra short-throw laser projector. Providing over 3,600 lumens of brightness[1] and Full HD 1080p technology, this ultra bright projector delivers vibrant, true-to-life images up to 110" (16:6) or 120" (16:9) diagonal, ideal for installation in small spaces. The perfect choice for creative signage applications, including in-store displays, museum exhibits and more, the PowerLite 755F arrives with free downloadable content management software[2] that lets you easily customize, playback and upload creative displays directly from the projector. Built with durability and reliability in mind, this projector also offers a long-lasting virtually maintenance-free 20,000-hour laser light source with no lamps to replace[3].

• 3,600 lumens of color and white brightness[1]
• Full HD 1080p resolution
• Project up to 110" (16:6); 120" (16:9) diagonal
• 20,000-hour laser light engine with no lamps[3]
• Built-in edge blending and split screen[4]
• Content management software[2] and creative content app for easy creation and management of content for digital signage

• Simple, flexible installation — 360-degree placement capabilities; mount or place the projector in any position or angle, from landscape to portrait
• Remote management and control tools — for ease of access and maintenance
• Built-in 5GHz wireless — supports Miracast or wireless display via Epson iProjection™[5]
• Eco Features

• Recyclable product[6]
• RoHS compliant
• Epson America, Inc. is a SmartWaySM Transport Partner[7]

What's In The Box:

• PowerLite 755F
• Quick Setup Guide
• Projector Remote Control
• 2x AA Batteries
• Power Cable
• Projector feet

• Ultra bright displays — 3,600 lumens of color and white brightness[1]
• High-quality images — Full HD 1080p resolution for true to-life images up to 110" (16:6) or 120" (16:9) diagonal
• Virtually maintenance-free — 20,000-hour laser light source[2] with no lamps to replace
• Free downloadable content management software and app[3] — create amazing effects and experiences with our easy-to-use, free content management software for digital signage; Epson Creative Projection app[3] lets you easily create custom content, plus upload and playback directly from the projector
• Easily project wall-sized images — built-in edge blending and split screen[4] features for larger-than-life dynamic content
• Convenient ultra short-throw design — projects large, easy-to-read images, even in small spaces
• Simple, flexible installation — 360-degree placement capabilities; mount or place the projector in any position or angle, from landscape to portrait
• Remote management and control tools — for ease of access and maintenance
• Built-in 5 GHz wireless — supports Miracast® or wireless display via Epson iProjection™[5]

Specifications

• General:
• Projection System: RGB liquid crystal shutter projection system
• Driving Method: Poly-Silicon TFT Active Matrix
• Pixel Number: 2,073,600 dots (1920 x 1080) x 3 chips
• Color Brightness[1]: Color Light Output: 3,600 lumens
• White Brightness[1]: White Light Output: 3,600 lumens
• Aspect Ratio:
• Supports 4:3, 16:10, 16:9*, 16:6*, 21:9*
• * With vertical image shift control within letterbox area.
• Image Size:
• 54" to 98" (0.38 m – 0.70 m) @4:3
• 60" to 110" (0.36 m – 0.69 m) @16:6
• 65" to 120" (0.37 m – 0.70 m) @16:9
• 65" to 110" (0.40 m – 0.67 m) @16:10
• Display Resolution: 1080p (1920 x 1080)
• Light Source: Laser Diode
• Laser Light Source Life[2]:
• Normal Mode: Up to 20,000 hours
• Extended Mode: Up to 30,000 hours
• Throw Ratio Range: 0.26 (Zoom: Wide), 0.36 (Zoom: Tele)
• Size (Projected Distance):
• 65" – 120" [0.37 m – 0.70 m] (Zoom: Wide) 16:9
• 60" – 110" [0.37 m – 0.69 m] (Zoom: Tele) 16:6
• Keystone Correction Manual:
• Vertical: ±3 degrees;
• Horizontal: ±3 degrees
• Dynamic Contrast Ratio: Over 2,500,000:1
• Color Reproduction: Up to 1.07 billion colors
• Foot Adjuster:
• Vertical: -0.8 to +0.8 degrees
• Horizontal: -0.8 to +0.8 degrees
• Modes:
• Dynamic
• Presentation
• Cinema
• sRGB
• DICOM SIM
• Multi-Projection
• Projection Lens:
• Type: Digital zoom, Focus (Manual)
• F-Number:1.6
• Focal Length: 3.7 mm
• Zoom Ratio: Digital zoom 1.0 – 1.35
• Software:
• In addition to compatibility with Epson’s standard suite of software, this product has a direct playback function via USB.
• Works with::
• - Epson® Projector Content Manager Software (visit our support pages for the latest version)
• - Epson Creative Projection application
• Interfaces:
• 3x HDMI®: (with CEC Control)
• 1x Analog D-Sub 15 pin (in)
• 1x RCA Composite
• 1x Analog D-Sub 15 pin (input/monitor out)
• 3x Stereo Mini In
• 1x Stereo Mini Out
• 1x RS-232C control port
• 1x USB Connector Type A: For saving and reading data,
• document camera
• 1 USB-A type for wireless adapter
• 1x USB Connector Type B: For USB Display
• 1x Wired LAN RJ-45
• Wireless support for built-in WLAN adapter: Wireless 802.11 b/g/n/ac
• IEEE 802.11 b: 11 Mbps* (2.4 GHz)
• IEEE 802.11 g: 54 Mbps* (2.4 GHz)
• IEEE 802.11 n: 72.2 Mbps* (2.4 GHz)
• IEEE 802.11 a: 54 Mbps* (5 GHz)
• IEEE 802.11 n: 150 Mbps* (5 GHz)
• IEEE 802.11 ac: 325 Mbps* (5 GHz)
• Other:
• Operating Temperature: 41 ˚F to 104 ˚F (0 ˚C to 40 ˚C) (20% – 80% humidity, no condensation)
• Power Supply Voltage: 100 V – 240 V AC ±10%, 50/60 Hz
• Auto Power On: Signal Detection on HDMI/Plug-In Detection (HDMI, USB, VGA 15 pin, BNC)
• Sleep Mode: Yes (with timer)
• Power Consumption:
• Normal Mode: 267 W
• Quiet Mode: 206 W
• Standby Mode: 2.0 W
• Energy-Saving Mode: 0.5 W
• Fan Noise:
• Normal Mode: 36 dB
• Quiet Mode: 26 dB
• Security: Enterprise Level Security Encryption
• Country of Origin: China
• Dimensions (W x D x H):
• Projector (Including Feet): 14.1" x 6.4" x 15.6"
• Weight: 12.5 lb
• Remote Control:
• Features: Source Search, HDMI, Computer, USB, LAN, Keystone, Effect, USB Viewer, ID, Default, User, E-Zoom, Color Mode, Aspect, A/V Mute, Split, Freeze, Home
• Operating Angle:
• Front: Right/left: -30 to +30 degrees
• Upper/lower: 0 to +60 degrees
• Rear: Right/left: -55 to +55 degrees
• Upper/lower: +75 to +15 degrees
• Operating Distance: 20 ft (6 m)
• Support:
• Epson ConnectionSM:
• Pre-sales support: U.S. and Canada (800) 463-7766
• Internet website: www.epson.com
• Service Programs:
• 3-year projector limited warranty or 20,000 hours, whichever comes first Epson Road Service program, dedicated toll-free support (U.S. and Canada only)

Notes:

[1] Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

[2] No required maintenance for the light source for up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 – 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period.

[3]Internet connection required for download. Data usage fees may apply.

[4] Split Screen feature requires remote control. Consult your user manual for input combinations.

[5] For wireless functionality, including via the Epson iProjection App, the projector must be configured on a network, either through the Ethernet port on the projector (check model specifications for availability) or via a wireless connection. Check your owner’s manual to determine if a wireless LAN module must be purchased separately to enable a wireless connection. Not all Epson projectors are able to be networked. The Epson iProjection App does not support all files and formats. See www.epson.com for details.

[6] For convenient and reasonable recycling options, visit www.epson.com/recycle

[7]SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
