Elation Therma Tour 800; 750W Oil based Hazer in
The Therma Tour 800 is a powerful oil-based haze effect generator that produces an exceptionally fine, long-lasting atmospheric haze that excels at revealing light beams and mid-air effects. The 800W THERMA TOUR 800 creates a safe, clean and odorless haze effect that leaves no residue. The perfect small-particle haze for highlighting light beams, the unit holds two liters of fluid for over 35-hours of run time with no warm up time required. Hang time is incredibly long at over 3 hours in an enclosed space! Compact yet ruggedly built to withstand the day in and day out rigors of on-the-road use, multiple control options include a wireless RF remote, MAGMATIC MAGFLY or Elation E-Fly wireless DMX, wired remote, MAGMATIC App, and manual, on-board, touch screen control.
Features
- 800 watt power consumption
- Over 30 hours of run time
- Haze lasting up to 3 hours after the machine is off
- Rugged mobile road case design
- Soundproof insulation for indoor use
Specifications
-
KEY FEATURES
- 800 Watt low power consumption
- Over 30 hours of run time
- Haze lasting up to 3 hours after the machine is off
- Rugged mobile road case design
- Soundproof insulation for indoor use
-
DYNAMIC EFFECTS
- Output: 5600 cu.ft / Min
- External Visual Fluid Level Detection
-
COMPATIBLE FLUID
- Atmosity ARH (Oil based fluid)
- Atmosity AAH (Water based fluid)
-
CONSTRUCTION / PHYSICAL / PERFORMANCE
- External Visual Fluid Level Detection
- Fluid Tank Capacity: 2.5L
- Fluid Consumption: 1.5ml / Min.
-
CONTROL
- 2 Card Inputs
- RDM (Remote Device Management)
- Control Protocol: DMX
- DMX Control Modes: 2 (1 3 Channel)
- On-Board Timer Control
- 5 Factory Presets
- 4-Pin Wired Remote Input for optional remote
- Touch Screen Display
- Manual Control via on-board display
- MagRemote VIDI
-
CONNECTIONS
- Data Connectors: 5-Pin XLR/Out, 4-Pin XLR Out
- Locking Power Connector
-
SIZE / WEIGHT
- Length: 24.45 in. (621.13mm)
- Width: 15.34 in. (389.63mm)
- Height: 19.87 in. (504.76mm - With Casters)
- Weight: 93 lbs. (42kg)
-
ELECTRICAL
- Power Consumption: 820w
- Input Voltage: 120V, 230V, 240V, 50 60Hz
- Breaker Size: 15A (120V version)
- Breaker Size: 10A (230V version)
-
THERMAL
- Maximum Temperature (Ambient): 104°F (40°C)
- Exterior Surface Temperature: 122°F (50°C)
-
WHATS INCLUDED
- Flight Case
- 14 AWG Locking Power Cable
-
OPTIONAL ACCESSORIES
- MAGFLY Card
- MAG-RF Card
- Atmosity ARH (Oil base haze fluid)
- Atmosity AAH (Water based fluid)
-
APPROVALS / RATINGS
- CE | cETLus | IP20 | UKCA
- Specifications and documentation subject to change without notice.
