Elation Platinum HFX 3 in 1 Moving Head DMX Light
The new Platinum HFX™ is a hybrid versatile 3-in-1 luminaire which can be utilized as a beam, spot, or wash fixture, featuring the brand new Philips™ MSD Platinum 14R 280W 80CRI lamp, 7,800K, 12,000 total lumens, 2.3° to 15° zoom in beam mode, 3° to 22° zoom in spot mode, and 10° to 34° zoom in wash mode, 13 dichroic colors including UV and a new Quad Color (RGBY) filter, CTO and CTB color correction, 8 rotating-interchangeable and 12 static-stamped gobos, 8-facet and linear rotating, and 10-facet static prisms, wash frost effects, DMX, RDM (Remote Device Management), KlingNET™ and Art-NET support, 5pin DMX, RJ45 Ethernet, and powerCON in/out connections, (6) button control full color 180° reversible menu display, and a multi-voltage universal auto switching power supply (100-240v).
FEATURES- Hybrid Beam, Spot, and Wash 3-in-1 Luminaire
- New Philips™ MSD Platinum 14R 280W 80CRI Lamp
- 12,000 Total Lumens, 7,800K, 1,500 average hours*
- 2.3° - 15° Beam, 3° - 22° Spot, and 10° - 34° Zoom
- 10-Facet, 8-Facet, and Linear Prisms / Wash Frost Effects
- 13 Dichroic Colors Including UV and Quad Color (RGBY)
- CTO and CTB CTO Color Correction
- 8 Rotating Interchangeable + 12 Static-Stamped Gobos
- RDM, KlingNET™ and Art-NET (DMX Over Ethernet)
- Philips™ MSD Platinum 14R 280W Lamp
- 1,500 Hour Average Lamp Life*
- *Lamp Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
- 12,000 Total Lumens, 7,800K, 80CRI
- 125,800 LUX 11,687 FC @49.2’ (15m) (2.3° Beam)
- 13,375 LUX 1,243 FC @49.2’ (15m) (3.0° Spot)
- 11,500 LUX 1,068 FC @16.4’ (5m) (10.8° Wash)
- 8-Facet and Linear Rotating and 10-Facet Static Prisms
- Strobe and Mechanical Dimming
- Zoom, Iris and Wash Frost Filter
- 13 Dichroic Colors Including UV and Quad Color (RGBY)
- CTO and CTB Color Correction
- (2) Gobo Wheels
- (8) Interchangeable / Rotating / Indexing Gobos
- (12) Static-Stamped Gobos (Indexing Wheel)
- (3) DMX Channel Modes (17 / 19 / 26)
- RDM (Remote Device Management)
- 6 Button Touch Control Panel
- Full Color 180° Reversible LCD Menu Display
- 8 / 16 Bit Resolution Adjustable Movement
- 5pin DMX In/Out
- RJ45 Ethernet In/Out (Art-NET)
- powerCON Power In/Out
- Length: 16.0" (406mm)
- Width: 11.5" (292mm)
- Vertical Height: 27.0" (686mm)
- Weight: 50.0 lbs. (22.7 kg)
- AC 100-240V - 50/60Hz
- 450W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
- CE | IP20
- Rigging: Clamps (Not Included)
