Elation Paladin Brick 24 x 15W RGBW IP65 Wash
The Paladin Brick™ is a compact and powerful outdoor flood light for a wide variety of applications. Using 24x15W RGBW cells it provides a total output of 9,600 lumens. Certified to IP65 it features a rugged design with a solid build quality, eliminating the need to worry about dust and water ingress. IP rated connections make it an ideal product to illuminate large areas of any outdoor event with vibrant and powerful colors. It can be operated standing on the floor or be hung in any orientation using the provided omega brackets. Available cell control and strobe features make the Paladin Brick also a versatile effects fixture or audience blinder.
Features:
- 360W RGBW Flood Light
- Multicell Control
- Rugged IP65 Design for Outdoor Events
- Floor Standing or Mountable in any Orientation
Specifications:
Source
- 24x 15W RGBW LED Emitters
- 100,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
Photometric Data (estimated)
- 6,000K Total Lumen Output, CRI 71
- 14° Beam 23° Field Angle (without diffuser)
- 22° Beam 45° Field Angle (with diffuser)
Control / Connections
- 11 DMX Channel Modes
- 3x2 Cell Control
- DMX, RDM Protocol Support
- Standalone and Master / Slave Operation
- 4 Button OLED Control Display
- 5pin IP65 DMX In/Out
- Seetronic IP65 Power In
- With Wired Digital Communication Network
Size / Weight
- Length: 17.3" (440mm)
- Height: 11.0" (280mm)
- Depth: 5.5" (140mm)
- Weight 21 lbs (9.5kg)
Electrical / Thermal
- AC 100-240V - 50/60Hz
- 400W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
Approvals / Ratings
- CE | cETLus (pending) | IP65
- 24x 15W RGBW LED Emitters
- 100,000 Hour Average LED Life*
- 6,000K Total Lumen Output, CRI 71
- 14° Beam 23° Field Angle (without diffuser)
- 22° Beam 45° Field Angle (with diffuser)
- 11 DMX Channel Modes
- 3x2 Cell Control
- DMX, RDM Protocol Support
- Standalone and Master / Slave Operation
- 4 Button OLED Control Display
- 5pin IP65 DMX In/Out
- Seetronic IP65 Power In
- With Wired Digital Communication Network
- Length: 17.3" (440mm)
- Height: 11.0" (280mm)
- Depth: 5.5" (140mm)
- Weight 21 lbs (9.5kg)
- AC 100-240V - 50/60Hz
- 400W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
- CE | cETLus (pending) | IP65
