DiGiCo SD12 96-Input Digital Mixing Console SD Package - MADI and One Multi-Mode Optics HMA
Compact in size but big on features, the SD12 96 raises the bar as a multi-application digital console at an exceptionally affordable price point. Not only is the SD12 96 a true sonic powerhouse, it is the first in the SD-Range to feature an integrated recording interface which makes virtual sound checking a snap.
Designed to provide optimum performance in live touring, corporate, install, house of worship, theatre, and broadcast environments, the SD12 96 incorporates the latest generation Super FPGA technology and Core 2 software to deliver unrivaled power and connectivity in a compact frame.
Designed for even easier operation, the SD12 96’s new DVI display output provides an overview of the console, while brighter LED meters and a DiGiCo Lightbar ensure optimum visibility. Dual 15-inch touchscreens, two assignable master faders, and advanced surface connectivity is provided in the form of optional DMI cards.
Features:
- 72 input channels with full processing
- 36 Aux/Sub-Group busses with full processing
- 12 x 8 matrix with full processing
- Assignable channel layout
- User programmable macros
- Capable of redundantly mirroring with another SD12 console
- Redundant PSUs as standard
- Snapshots for seamlessly changing many parameters at once
- 2 DMI slots to expand the I/O as desired
- Integrated UB MADI
- Offline software
- iPad control
- SD12 96 software option
- Theatre software option
Specifications:
- Faders: 26 x 100mm touch-sensitive, motorised
- Screens: 2 x 15” LCD high-resolution touch screens
- Input channels: 96
- Busses: 48 plus masters Aux / Group busses with full processing (Mono / Stereo / LCR)
- Matrix: 12 input / 8 outputs with full processing
- Control groups: 12, selectable for VCA-style, moving fader, mute group
- Graphic EQ: 16 x 32-band, gain +/- 12dB
- Internal FX: 12 stereo effects comprising of reverbs and delay/chorus/pitch/enhancer
- Local I/O: 8 x mic/line I/O, 8 x AES I/O
- MADI interface: 2 interfaces, BNC connectivity
- Optic interface: One Multi-Mode Optics HMA
- Sampling rates: 48kHz / 96kHz
- GPIO: 2 x DSub37
- DMI: 2 x DiGiCo Multichannel Interface
- External sync: Wordclock, MADI, optics
- SD12 dimensions: 1124 mm (W) x 795 mm (D) x 389 mm (H)
- SD12 weight: 42Kg / 96lbs (130Kg / 287lbs with optional flightcase)
- SD12 flightcase: 1270 mm (W) x 570 mm (D) x 1150 mm (H)
- SD12 power requirements: 90V-260V, 50-60Hz, 150VA (140W)
