Datavideo HDR-10 Highlight Replay Recorder with HD/SD-SDI I/O
Datavideo HDR-10 Highlight Replay Recorder with HD/SD-SDI I/O
SKU: HDR-10
Available options
Description
Datavideo HDR-10 Highlight Replay Recorder with HD/SD-SDI I/O
Simple instant replay
Video production team can use with slow motion to review plays for referees and coaches during games and matches.
multi-resolution for different cameras
Supports 1080p/1080i/720p video resolutions
Capture and review the highlight
Built in internal 4GB (30sec.) buffer can be used in the highlights of the event, the captured video can be repeated in speed or playback mode to seize the perfect moment.
GPI interface
Allows other devices such as a switcher to trigger the playback.
Easy-to-use control device available
The RMC-400 as a control input device can command up to four HDR-10 instant replay units simultaneously. Shortcut keys and jog wheel make performing live instant replay a breeze.
Specifications
| HDR-10 Instant Replay | |
|---|---|
| Video Standard |
HD |
| Video Format |
1080p 50/59.94/60 (3G support Level A signal only) |
| Supported Video Input Signal |
1x SDI |
| Monitoring / Playback Output |
2x SDI |
| Embedded Audio |
SDI Input |
| Storage Medium |
Internal 4GB Buffer / SSD |
| Recording Media |
Removable Hard Drive / SSD |
| Storage File System |
NTFS (read only) |
| Recorded File Format |
MOV |
| Video Recording Bit Rate / Color Sampling |
Uncompressed 10-bit |
| Audio Recording Format |
Uncompressed PCM |
| Time Code In / Out |
Via embedeed SDI only |
| External Sync / Genlock |
LISN |
| Chassis |
Rack-mountable with RMK-2 2U Rackmount Kit |
| Dimension (LxWxH) |
85 x 174 x 42 mm |
| Weight |
0.6 kg |
| Operating Temp. Range |
0~40 °C |
| Power |
DC 12V, 1A |
