Crestron SAROS SB-200-P-B Saros Sound Bar 200, Powered, Black

Crestron SAROS SB-200-P-B Saros Sound Bar 200, Powered, Black

The Saros® SB-200-P is a stereo sound bar designed to provide enhanced audio performance for a flat panel display. Its full-range, front-firing speakers offer an improvement over the small, rear-facing speakers typical of many display devices. The bracket included with the sound bar allows for attachment to a wall surface, or the unit can be placed on a shelf below or above the display.

Built-in amplification allows for direct connection to the line-level audio output of the display device, or to the output of an audio preamp, switcher, mixer, tv tuner, codec, or Crestron DM® receiver.^[1] The amplifier powers on automatically when an audio input signal is detected, and powers off if no signal is detected for several minutes.

The SAROS SB-200-P sound bar is ideally suited for use with the Crestron RL® 2 Group Collaboration System and other unified communication and videoconferencing systems. It is equally well-suited for use in any small to medium sized room or public space in a hotel, restaurant, museum, medical center, airport, office building, or residence.

Key Features

• High-quality, full-range amplified stereo sound bar
• Delivers enhanced sound quality and performance for use with any flat panel display
• Mounts to a wall or sits on a shelf
• Balanced or unbalanced stereo line-level audio input ^[1]
• Unbalanced stereo audio cable included
• Powers on and off automatically
• 100 to 240 Volt AC powered

Specifications

Features & Performance

• Woofers: (2) 3 inch (76 mm) polypropylene cone w/rubber surround
• Passive Radiators: (2) 3 x 4-3/8 inch (76 x 112 mm) polypropylene cone w/rubber surround
• Tweeters: (2) 1 inch (25 mm) polyester dome
• Amplifier Power: 20 Watts per channel, stereo
• Frequency Response: 100 Hz to 20 kHz (±3 dB)
• Output Sensitivity: 83 dB SPL @ 1 meter, both channels driven @ 1 Watt each
• Input Sensitivity: 0.75 Vrms per channel for full rated output
• Go To Sleep Time: 20 minutes (±5 minutes) with no signal present
• Wake Threshold: 5 mV (±2 mV) typical

Connectors

• BALANCED AUDIO INPUTS: (1) 5-pin 3.5 mm detachable terminal block; Balanced stereo line-level audio input [1]; Maximum Input Level: 0.85 Vrms; Input Impedance: 10k Ohms
• UNBALANCED AUDIO INPUTS: (2) RCA connectors, female; Unbalanced stereo line-level audio input [1]; Maximum Input Level: 0.85 Vrms; Input Impedance: 10k Ohms; NOTE: Right-angle plugs may be required for wall mount applications. A 59 inch (150 cm) right-angle RCA to straight RCA stereo cable is included.
• 100-240V~50/60Hz 50W: (1) IEC 60320 C8 main power inlet; Mates with removable power cord, included

Controls & Indicators

• 100-240V~50/60Hz 50W: (1) Rocker switch, turns main power on or off
• PWR: (1) Blue LED, indicates the main power switch is turned on

Power Requirements

• Main Power: 50 Watts (500 mA maximum) @ 100-240 Volts AC, 50/60 Hz

Environmental

• Temperature: 41° to 104° F (5° to 40° C)
• Humidity: 10% to 90% RH (non-condensing)

Construction

• Enclosure: Plastic housing with perforate metal grille, black
• Mounting: Freestanding or wall mount (bracket included)

Dimensions

• Height: 4.18 in (106 mm)
• Width: 40.60 in (1031 mm)
• Depth: 2.78 in (71 mm); 2.96 in (76 mm) with wall mount bracket

Weight

• 7.8 lb (3.6 kg)
