Clear-Com CCT-RT Tempest2400 2.4 GHz Remote Transceiver

Clear-Com CCT-RT Tempest2400 2.4 Gigahertz Remote Transceiver

The Tempest Remote Transceiver is an optional accessory that allows antennas to be located up to 1,500 feet away from the Tempest2400 BaseStation without the RF signal loss that is associated with using long runs of coaxial cable. The Tempest Remote Transceiver connects to the rear of the BaseStation with standard CAT-5 wiring with RJ-45 connectors. Note that there are two RJ-45 connectors on the back of the BaseStation and they are not interchangeable. The second RJ-45 is for a LAN connection. The Transceiver antenna connectors are made to be water resistant, so outdoor use is acceptable. The cable connections on the bottom of the transceiver are not water tight, so always protect from immersion. In severely blowing rain, it may be prudent to protect with an RF transparent cover.

Specifications:

• Maximum Distance, Base to Transceiver: 1,500 ft., powered from the base station.
• Connection to base station: CAT-5 standard wiring.
• Base stations Supported per Transceiver: 1.
• Number of Antenna Ports per Transceiver: 2.
• Antenna Connector Type: RP-TNC.
• Supplied Antenna: Whip antenna, 2 each.
• Dimensions with Antennas (inches): H 12" x W 3.7" x D 1.7".
• Weight: 11 oz.
• Operating Environment: -20° to 50° C (-4° to 122° F) -> 10% to 90% Humidity.
