Chauvet Professional ROGUEOUTCAST1BWM Rogue Outcast 1 BeamWash M

Chauvet Professional ROGUEOUTCAST1BWM Rogue Outcast 1 BeamWash M

A rugged, IP66 and marine-grade rated beam and wash moving head that delivers versatile effects through seven powerful RGBW LEDs and a 12-zone pixel-mappable outer ring. Ideal for demanding applications like touring, cruise ships, theme parks, and architectural exteriors requiring robust, all-weather performance.

• Delivers an expansive zoom range from a tight 3.9° beam to a broad 55.3° wash.
• Built with a C5M marine-grade finish and full aluminum construction for extreme weather durability.
• Achieves exceptionally smooth fades with 16-bit dimming and a selectable calibrated white of 7500 K.
• Powered by seven high-output 45W RGBW LEDs for intense, smoothly blended color washes.
• Supports DMX and RDM protocols with six DMX personalities for ultimate programming versatility.
• Ensures flicker-free on-camera performance with user-selectable Pulse Width Modulation settings.

Rogue Outcast 1 BeamWash M brings layers of external corrosion resistance with its full aluminum construction, C5M marine-grade finish, and rugged IP66 build engineered with the enhanced protections needed to perform extended duty in and near marine environments. Seven 45W high-powered RGBW LEDs and a unique lens design deliver smoothly blended color washes and tight beam effects, while a 12-zone pixel-mappable outer ring provides limitless creative possibilities. Create dynamic looks while withstanding the most demanding environments, whether on tour, cruise ships, or lighting theme park and architectural exteriors.

• RGBW LED Wash Fixture: A fully featured and IP66 rated yoke wash fixture with zoom and a dynamic RGB LED ring.
• C5M Marine-Grade Construction: A C5M paint process, full aluminum construction, and stainless steel hardware ensure extended use in marine environments.
• Protective Display Cover: An included display cover enhances durability for extended outdoor and marine usage.
• 16-Bit Dimming Control: Achieve exceptionally smooth fades with 16-bit dimming of the master dimmer and individual colors.
• Pixel-Mappable LED Ring: A 12-zone pixel-mappable RGB LED outer ring under a stealth filter adds compelling visual effect possibilities.
• 5-Pin DMX Connections: Includes professional 5-pin DMX input and output connections for reliable data linking.
• Prebuilt Ring Programs: Easily control prebuilt effects for the outer LED ring, including dimming, rate, and color selection.
• Unique Lens Design: A specialized lens design provides excellent color blending and creates tight, well-defined beam effects.
• RDM Enabled: Allows for remote addressing and troubleshooting, simplifying setup and maintenance.
• Selectable PWM Settings: Ensures flicker-free performance on camera with user-selectable Pulse Width Modulation settings.
• Wide Zoom Range: Offers an expansive zoom from a narrow 3.9° to a wide 55.3° for maximum coverage flexibility.
• Selectable Calibrated White: Includes a user-selectable calibrated white option of 7500 K at full output.
• Six Distinct Dimming Modes: Choose from six different dimming modes for advanced and customized control.
• Easy-to-Read OLED Display: A clear OLED display with a simple menu structure provides effortless navigation and configuration.
• Flexible DMX Channel Profiles: Offers both simple and complex DMX channel profiles for programming versatility.
• USB-C Software Port: A convenient USB-C port allows for fast and easy software uploads.

Optical

• Light Source: 7 LEDs (quad-color RGBW) 45W, (3 A), 50,000 hours life expectancy
• Light Source: 97 LEDs Outer Ring (tri-color RGB) 0.2 W, (20 mA), 50,000 hours life expectancy.
• Color Temperature (range): 2800 to 10000 K
• Beam Angle: 9.1° to 32.3°
• Field Angle: 11.2° to 49.2 °
• Zoom Range: 3.9° to 55.3°
• Zoom Angle: 11° to 63.2 °
• Lumens – Source: 5,900
• Lumens – Output: 4,073
• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects

• Pan and Tilt: 540°/260°
• Pan and Tilt Ranges: 180°, 360°, 540° Pan/90°, 180°, 260° Tilt.
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 20 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Curves: 4
• Built-in Automated Programs: Yes
• Customizable Programs: No
• Recall Custom Programs: No

Construction/Physical

• Dimensions: 11.92 x 7.58 x 15.75 in (303 x 192 x 391 mm)
• Weight: 20.2 lb (9.16 kg)
• Exterior Color: White
• Housing Material: Aluminum

Connections

• Power Connection: Edison (local) plug to Seetronic PowerKON IP65
• Data Connectors: 5-pin XLR
• Cable Length (power input): 5 ft (1.5 m)
• Cable Length (signal in/out): 5 ft (1.5 m)

Control

• Control Protocol: DMX, RDM
• DMX Channels: 15, 24, 30, 64, 111 or 135
• Modes/Personalities: 6 personalities (15, 24, 30, 64, 111, 135)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 3 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
• Power and Current: 385 W, 3.25 A @ 120 V, 60 Hz
• Power and Current: 376 W, 1.92 A @ 208 V, 60 Hz
• Power and Current: 372 W, 1.69 A @ 230 V, 50 Hz
• Fuse Size: 8A, 250 V

Certifications/Qualifications

• Certifications: CE, MET, FCC, FCC, UKCA
• IP Rating: IP66, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
• Maximum Exterior Surface Temperature (Tc): 80° C / 176° F
• Maximum Ambient Temperature (ta): 45° C / 113° F
