An IP65-rated ERS-style fixture offering high-performance, full RGBA-Lime color mixing, adjustable color temperature presets, and a virtual color wheel for versatile theatrical lighting. Perfect for outdoor theatrical productions, amphitheaters, and event spaces where a high-quality, weather-resistant ERS fixture with precise color control is required.

• Features a 91-LED RGBA-Lime engine for a full spectrum of rich colors and high CRI.
• Housed in an IP65-rated enclosure for dependable, all-weather theatrical and event lighting.
• Utilizes standard Ovation lenses and shutters for seamless integration and familiar operation.
• Delivers smooth 16-bit dimming fades and flicker-free operation with selectable PWM settings.
• Projects sharp, high-contrast gobos with an exceptionally flat and even field of light.
• Offers flexible control with multiple DMX personalities and RDM for remote device management.

Ovation E-910FC IP takes the high-performance, full RGBA-Lime color-mixing marvel of the Ovation E-910FC outdoors. Our standard shutter assembly and lenses lend familiarity and ease of use to this IP65 ERS style fixture that offers Color Temperature presets of 2800 to 6500 K that match the output of a tungsten source to perfection. Control options include full bit dimming (per color and master), selectable PWM, RDM and onboard dimming curves selection. Also accessible is our virtual color wheel which matches popular color gels.

• Full Color ERS Style Fixture: This RGBAL LED light provides rich, vibrant color for theatre, film, and production applications.
• IP65 Weatherproof Rating: A fully IP65 rating ensures reliable performance for seasonal use both indoors and outdoors.
• Standard Ovation Optics: The fixture is compatible with standard Ovation beam shaping shutters and lenses for familiar operation and ease of use.
• Virtual Color Wheel: Access a virtual color wheel with colors precisely matched to the most popular gel filters.
• Adjustable Color Temperature: Select from a range of color temperature presets from 2800 K to 6500 K, all with high CRI and CQS for accurate color rendering.
• Advanced Dimming Control: Achieve ultra-smooth fades with 16-bit dimming, plus 8-bit dimming curves to match any lighting scheme.
• Superior Gobo Projection: A flat and even field of light ensures crisp, high-quality gobo projection.
• Remote Device Management: RDM functionality is included for increased flexibility in setup and configuration.
• Flicker-Free Operation: Adjust the Pulse Width Modulation (PWM) to ensure flicker-free performance on camera.

Optical

• Light Source: 91 LEDs (18 red, 18 green, 19 blue, 18 amber, 18 lime green) 3 W, (722 mA), 6031 K, 50,000 hours life expectancy
• Color Temperature (range): 2800 to 6500 K
• Color Temperature (at full): 6031 K
• CRI (3200 K): 86
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25000Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Focus: Manual
• Strobe Rate: 0 to 28 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes

Construction/Physical

• Exterior Color: Black
• Gobo Size (Optional): “A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
• Gobo Size (Optional): “B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)

Connections

• Power Connection: Edison (local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

Control

• Control Protocol: DMX, RDM
• DMX Channels: 1, 4, 6, 8, 11, 13, 14, 16 or HSV
• Modes/Personalities: 9 personalities (1, 4, 6, 8, 11, 13, 14, 16 or HSV)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 7 units @ 120 V; 11 units @ 208 V; 12 units @ 230 V
• Power and Current: 225 W, 1.88 A @ 120 V, 60 Hz
• Power and Current: 236 W, 1.14 A @ 208 V, 60 Hz
• Power and Current: 241 W, 1.05 A @ 230 V, 50 Hz

Certifications/Qualifications

• Certifications: CE, MET, FCC
• IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
