Chauvet Professional OVATION2WL Ovation 2wl

Chauvet Professional OVATION2WL Ovation 2wl

A high-CRI utility flood light that operates on direct line voltage and dims with standard phase-cut or triac dimmers without needing any DMX control.

• Effective utility light for use when DMX lighting isn’t needed.
• Three selectable color temperatures (3200, 4000, 5600K) providing wide-spectrum, high-CRI lighting
• Soft, flood lighting minimizes shadows
• Use with direct line voltage and can be dimmed via off-the-shelf phase cut or triac dimmers

Useful for times when DMX lighting isn’t needed, this effective utility light is powered by direct line voltage and can be dimmed via off-the-shelf phase-cut or triac dimmers. Projecting a soft flood light that minimizes shadows, Ovation 2WL offers selectable 3200K, 4000K, and 5600K color temperatures that provide wide-spectrum, high-CRI lighting.

• Simple Non-DMX Operation: Integrates seamlessly into any system using direct line voltage, eliminating the need for DMX control in utility lighting applications.
• Selectable High-CRI Output: Choose between three high-CRI color temperatures to perfectly match ambient lighting for broadcast, theatre, or architectural environments.
• Soft, Even Flood: A wide, soft flood beam minimizes shadows and provides smooth, even coverage for general area illumination or houselighting.
• Standard Dimmer Compatibility: Achieve smooth dimming using conventional off-the-shelf phase-cut or triac dimmers, allowing for simple and cost-effective system integration.

Optical

• Light Source: 960 LEDs (CW, WW)
• Color Temperature (3200k): 3217 K
• Color Temperature (4000k): 3960 K
• Color Temperature (5600k): 5584 K
• CRI (3200K): 95.3
• CRI (4000K): 95.2
• CRI (5600K): 94.0
• Beam Angle: 107.4°
• Field Angle: 158.7°
• Lumens (3200k): 10,564
• Lumens (4000k): 10,954
• Lumens (5600k): 11,328
• Illuminance 3200k): 158 lux @ 5 m
• Illuminance (4000k): 164 lux @ 5 m
• Illuminance (5600k): 169 lux @ 5 m

Dynamic Effects

• Dimmer: External Dimmer (phase cut or triac compatible)
• Color Temperature Selection: On-board Color Temperature Selection

Construction/Physical

• Dimensions: 17.51x 11.06 x 5.47 in (445 x 281 x 139 mm)
• Weight: 10.2 lb (4.6 kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy
• Accessory Holder/Gel Frame Size: 14.375 x 8.50 x 0.125 in (365.125 x 216 x 3.175 mm)

Connections

• Power Connection: Edison (local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Cable Length (power): 5 ft (1.5 m)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 13 units @ 120 V; 21 units @ 208 V; 23 units @ 230 V
• Power and Current: 103 W, 0.91 A @ 120 V, 60 Hz
• Power and Current: 99 W, 0.55 A @ 208 V, 60 Hz
• Power and Current: 98 W, 0.51 A @ 230 V, 50 Hz
• Breaker Size: T2.5 A, 350 V

Certifications/Qualifications

• Certifications: CE, MET, FCC, RoHs
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
