A compact and lightweight LED moving profile delivering a powerful 18,963 lumens of output, featuring an expansive 18:1 zoom, a four-blade framing system, CMY color mixing, and a complete effects package. Perfect for a wide range of short and long-throw applications in touring, theatre, and broadcast where a versatile, feature-rich fixture is essential.

• Features a powerful 520W cool white LED engine for intense, crisp projections.
• Delivers a versatile 3.5° to 57.3° zoom range with a flat field of focus.
• Offers a variable CMY system and color wheel with CRI and CTB filters.
• Includes dual gobo wheels, a 5-facet prism, iris, and frost for dynamic effects.
• Ensures flicker-free operation on camera with high-speed PWM and 16-bit dimming.
• Supports DMX, Art-Net, sACN, and CRMX protocols for comprehensive control integration.

With superb dimming performance, an expansive 18:1 zoom, and a full armory of features, Maverick Force X Profile is a compact LED moving profile ready for a wide range of short and long throw applications. This fast lightweight powerhouse combines the latest Maverick series technical advancements to achieve 18,963 lumens of output in a design that maintains a flat field of focus all the way from its narrow 3.5° beam to a broad 57.3° spot. Color calibration and gobo selection comes matched to other Force fixtures in the rig, along with an advanced 4-blade shutter frame system and a wheelhouse that includes a variable CMY color mixing system renowned for its real reds, color wheel with CRI and CTB filters, static and rotating gobo wheels, five-facet prism, iris, and frost. Take control with DMX, RDM, sACN, Art-Net, or CRMX.

• Compact LED Profile Fixture: A fully featured, compact, and lightweight 520W LED yoke profile fixture.
• Variable CMY Color Mixing: Create a wide pallet of colors using the integrated CMY color mixing system and a separate color wheel.
• Dual Gobo Wheels: Expand creative options with two gobo wheels, one featuring rotating gobos and one with static gobos.
• Smooth 16-Bit Dimming: Achieve exceptionally smooth control of fades with 16-bit dimming of the master dimmer.
• High-Speed PWM: A 65,000 PWM ensures flicker-free operation for use with the fastest frame cameras while maintaining fantastic dimming.
• Flexible Control Options: Offers full flexibility of control with support for DMX, WDMX, sACN, and Art-Net.
• RDM Enabled: Allows for remote addressing and troubleshooting for simplified fixture management.
• Wide Zoom Range: Accommodate variable beam sizes with an expansive 3.5° to 57.3° zoom range.
• Advanced Beam Control: Shape and modify the beam using the built-in iris, 5-facet prism, and frost effects.
• Rotatable Framing System: Utilize a 4-blade framing shutter system with dual-axis movement, full wipe, and 120-degree module rotation.
• Professional Power Input: Features a secure, True-1 compatible power input for reliable connections.
• Easy Shop Setup: Three setup menu presets and a preset sync function allow for easy cross-loading to multiple fixtures.
• USB Software Updates: Keep the fixture’s software current using the convenient onboard USB slot for uploads.
• Battery Backup Display: Access the menu without main power thanks to the battery-backed display that auto-rotates depending on fixture orientation.
• Failsafe Ethernet Connectivity: Allows data to pass through to the next fixture even if the unit’s power is lost.
• NFC Configuration: Quickly and easily set up the fixture in the shop or field using Near Field Communication.

Optical

• Light Source: 1 LEDs (CW) 520 W, (4.2A), 6966 K, L70 rating: 22,938 Hours under LED manufactures test conditions (LM-80: 6,000 hrs)
• Color Temperature (at full): 6966 K
• Front lens diameters: 145 mm
• CRI: 72.2
• CQS: 70.2
• TLCI: 51
• CRI with CRI filter: 91.9
• CQS with CRI filter: 90
• TLCI with CRI filter: 78
• CTB filter color temperature: 8200K
• Beam Angle: 3.4° to 52.2°
• Field Angle: 3.7° to 55.3°
• Cutoff Angle: 3.8° to 57.3°
• Zoom Range: 3.5° to 57.3°
• Lumens – Output: 18,963
• Illuminance (3.4°): 104,429 lux @ 5 m
• Illuminance (57.3°): 1,219 lux @ 5 m
• Selectable PWM: 600Hz, 1500Hz, 2000Hz 65000Hz

Dynamic Effects

• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors: Colors: 7 (Red, Orange, Magenta, CTO 4300k, CTO 3200K, CRI and CTB filters) + white, split colors, continuous scroll at variable speeds
• Colors: CMY wheels
• Color Macros: CMY macros
• Gobos (1): Gobos (1): 7 + open (1 metal + 6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): Gobos (2): 9 + open (9 metal), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating): 23.9 mm (outside), 14 mm (image), 1.1 mm (max. thickness)
• Framing Shutters: Yes
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Focus: Motorized
• Frost: Motorized
• Iris: Motorized
• Prism: 5 Facets, motorized, rotating
• Strobe Rate: 0 to 25 Hz
• Move-in-Black: Yes
• Dim Curves: 5

Construction/Physical

• Dimensions: 14.21 x 9.40 x 25.43 in (361 x 239 x 646 mm)
• Weight: 50 lbs (23.1 kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy, Aluminum die-cast, High-impact flame-retardant polymer, Steel

Connections

• Power Connection: Edison plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin IP65 XLR, Seetronic etherCON
• Cable Length (power): 5 ft (1.5 m)

Control

• Control Protocol: DMX, Art-Net, sACN, CRMX, NFC
• DMX Channels: 31 or 47
• Art-Net Channels: 31 or 47
• Modes/Personalities: 2 personalities (31, 47)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 2 units @ 120 V; 4 units @ 208 V;4 units @ 230 V
• Power and Current: 595 W, 5.98 A @ 120 V, 60 Hz
• Power and Current: 576 W, 2.82 A @ 208 V, 60 Hz
• Power and Current: 580 W, 2.58 A @ 230 V, 50 Hz

Battery

• Battery type: Lithium Ion (display screen backup)
• Rechargeable: Yes
• Battery Charge Time: 5 hours
• Battery Life: 1 hours
• Battery Power: 3.7V, 500 mAh

Certifications/Qualifications

• Certifications: CE, MET, FCC, FCC, UKCA
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
