Chamsys CHAMMMSDI2 MediaMaster Vision-SDI2 Card (2 x SDI)
Chamsys CHAMMMSDI2 MediaMaster Vision-SDI2 Card (2 x SDI)
SKU: CHAMMMSDI2
Regular price
$3,715.00
Sale price
$3,715.00
Shipping calculated at checkout.
Available options
Description
Chamsys CHAMMMSDI2 MediaMaster Vision-SDI2 Card (2 x SDI)
Add dual channel SDI video input capabilities with this stand alone PCI Express four lane plug in card that brings 650MB/s transfer bus bandwidth to MediaMaster VS2+ or VS4+ media servers running MediaMaster software. The MediaMaster Vision SC-SDI2 HD-SDI video capture card supports SD-SDI, HD-SDI and 3G-SDI.
Hardware Specifications:
- Motherboard Connection Type: PCIe x8
- Input Connectors: 4 x BNC/SDI for Inputs and Outputs
Software Specifications:
- Maximum Capture Resolution: 2x 2048×1556 at 24fps, 2x 1920×1080 at 60fps
- Update Rate: User defined, captured frame rate will match the source. Providing max data rate (650 MB/s) is not exceeded Multi-buffered to eliminate tearing artifacts
- Maximum SDI Bitrate: 3Gb/s
- Supported Frame Rates: 23-98Hz, 24Hz, 25Hz, 29-97Hz, 30Hz, 50Hz, 59-94Hz &60Hz
- Sample Formats: RGB: 5-5-5, 5-6-5 or 8-8-8 (24 bit/32 bit) pixels, YUV: 4:2:2, MONO: 8 bit
- Frame Buffer Memory: 64 MB per channel (total 128 MB).
Included Accessories:
- VS4+ Rear Panel Adapter Plate: 1
Boxed Weights and Dimensions:
- Width: 280mm (4.09 inches)
- Depth: 170mm (4.09 inches)
- Height: 75mm (4.09 inches)
- Weight: 0.35 KG (0.77 lb)
