Blackmagic Design USMRECTB 10-Bit SDI and HDMI
Blackmagic Design BMD-BDLKULSDZMINREC is a mini recorder that fits in your pocket, UltraStudio Mini Recorder is super tiny and includes just SDI and HDMI connections plus Thunderbolt. Simply plug in and record from any SDI and HDMI device for the most incredible portable solution.
Specifications:
- Connections:
- SDI Video Inputs: 1 x 10 bit SD/HD switchable.
- SDI Audio Inputs: 8 Channels embedded in SD and HD.
- HDMI Video Inputs: 1 x HDMI type A connector.
- HDMI Audio Inputs: 8 Channels embedded in SD and HD.
- Computer Interface: ThunderboltT
- Supported Codecs: AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2.
- Software
- Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility, and Blackmagic driver on Linux.
- Internal Software Upgrade: Firmware built into software driver. Software driver loads upgrades at system start or via updater software.
- Video Standards:
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards: 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60
- SDI Compliance: SMPTE 259M and 292M.
- SDI Metadata Support: RP 188/SMPTE 12M-2 and closed captioning.
- Audio Sampling: Television rate of 48kHz and 24 bit.
- SDI Color Precision: 8-bit & 10-bit YUV 4:2:2
- SDI Video Sampling: 4:2:2
- Color Space: REC 601, REC 709
- HDMI Video Sampling: 4:4:4, 4:2:2 & 4:2:0
- HDMI Resolution: Pixel for pixel HD resolution input from connected device.
- HDMI Color Precision: 10 bit
- Multiple Rate support: SDI and HDMI are switchable between standard definition and high definition.
- Copy Protection: HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
- Processing:
- Colorspace Conversion - Hardware based real time.
- HD to SD Down Conversion: Software based down conversion during video capture.
- HD Up Conversion: Software based up conversion from SD to 720HD or 1080HD on capture. Selectable between 4:3 pillarbox or 16:9 anamorphic.
- Physical Installation: Requires computer with a ThunderboltT port. Please check the Support pages to see the full system requirements.
- Operating Systems:
- Windows 8.1 and 10, both 64-bit.
- Mac 10.14 Mojave, Mac 10.15 Catalina or later.
- Linux
- Power Requirements: Powered by Thunderbolt cable.
- EMC Certifications: FCC, CE, and C-Tick.
- Environmental Specifications:
- Operating Temperature: 5° to 40° C (32° to 104° F)
- Storage Temperature: -20° to 45° C (-4° to 113° F)
- Relative Humidity: 0% to 90% non-condensing
- SDI Video Inputs: 1 x 10 bit SD/HD switchable.
- SDI Audio Inputs: 8 Channels embedded in SD and HD.
- HDMI Video Inputs: 1 x HDMI type A connector.
- HDMI Audio Inputs: 8 Channels embedded in SD and HD.
- Computer Interface: ThunderboltT
- Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility, and Blackmagic driver on Linux.
- Internal Software Upgrade: Firmware built into software driver. Software driver loads upgrades at system start or via updater software.
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards: 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60
- SDI Compliance: SMPTE 259M and 292M.
- SDI Metadata Support: RP 188/SMPTE 12M-2 and closed captioning.
- Audio Sampling: Television rate of 48kHz and 24 bit.
- SDI Color Precision: 8-bit & 10-bit YUV 4:2:2
- SDI Video Sampling: 4:2:2
- Color Space: REC 601, REC 709
- HDMI Video Sampling: 4:4:4, 4:2:2 & 4:2:0
- HDMI Resolution: Pixel for pixel HD resolution input from connected device.
- HDMI Color Precision: 10 bit
- Multiple Rate support: SDI and HDMI are switchable between standard definition and high definition.
- Copy Protection: HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
- Colorspace Conversion - Hardware based real time.
- HD to SD Down Conversion: Software based down conversion during video capture.
- HD Up Conversion: Software based up conversion from SD to 720HD or 1080HD on capture. Selectable between 4:3 pillarbox or 16:9 anamorphic.
- Physical Installation: Requires computer with a ThunderboltT port. Please check the Support pages to see the full system requirements.
- Windows 8.1 and 10, both 64-bit.
- Mac 10.14 Mojave, Mac 10.15 Catalina or later.
- Linux
- Operating Temperature: 5° to 40° C (32° to 104° F)
- Storage Temperature: -20° to 45° C (-4° to 113° F)
- Relative Humidity: 0% to 90% non-condensing
