Blackmagic Design BM SDI Audio Converter

The Blackmagic Design CONVMCAUDS includes everything you need to embed 4 channels of analog audio, or 8 channels of AES/EBU digital audio into any SDI video connection. Embed audio from devices such as audio mixers and analog decks into SDI video connections for use with SDI routers and decks or to add extra audio channels to video converters.

Specifications:

• SDI Input:
  • SDI: Switchable between SD, HD, and 3 Gb/s SDI
  • SDI Redundant: Automatically switches over if main SDI input is lost
• Analog Audio: 4 channels of professional balanced analog audio with standard 1/4 inch jack connections
• AES/EBU: 8 channels of professional balanced digital with standard 1/4 inch jack connections
• Format: 625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60
• Sampling: 4:2:2
• Power Requirements: 12VDC (includes power supply)
• Packaging Info
  • Package Weight: 1.065 lbs.
  • Box Dimensions (LxWxH): 5.75 x 5.55 x 2.6"
