Audient Id22 2-Channel USB2 Audio Interface

Audient Id22 2-Channel USB2 Audio Interface

10in/14out Audio Interface
iD22 delivers the audio performance of a large format console in a compact and elegant desktop package. Providing two Audient console mic pres, class-leading Burr Brown converter technology, console style monitor control, JFET D.I, ADAT expandability, user defined function keys, balanced inserts and more, iD22 will become the hub of your studio in no time.

Audient Console Mic Pres: The professional sound you deserve
They are the only company that use the same Class-A mic pre design throughout their entire product range, whether you’re in the studio with an Audient console or on the road with iD22, you’re always guaranteed the same world class Audient sound.

Pristine Converter Technology: Brilliance on the inside enables brilliance on the outside
iD22 provides you with high performance AD-DA converters from Burr Brown, the leaders in converter technology. Quality in the analogue stages of design comes from years of experience as analogue console designers, and when coupled with outstanding converter technology it enables you to hear audio as it’s supposed to sound. The importance of converters should never be underestimated. Experience audio the Audient way.

Expand: Grows with your needs
iD22 is more than just a two in, six out interface. As your system grows iD22 can be expanded via the optical input and output connectors, supporting both ADAT and SPDIF. If you need to track drums or simply need more inputs you can expand up to ten inputs via an eight-channel mic pre such as their ASP880.

Balanced Inserts: Integrate your outboard
Two fully balanced insert points enable you to bring your outboard gear in from the cold and prior to conversion. Insert your favourite compressors or EQs and start creating vocal chains that rival the very best. The insert return also gives you direct access to the analogue to digital converters - providing the cleanest signal path possible, making it great for print-backs or integrating outboard line level sources.

Plug And Play: Plug in and be inspired
As well as offering you 2 channels of mic pre, iD22 has a harmonically rich JFET D.I input. Designed to replicate the input stage of a classic valve amplifier, you can plug your guitar, bass, keyboard or drum machine straight in and start recording instantly

Listen: You can't unhear quality
During iD22's development they discussed ways in which they could showcase iD22's versatility in a variety of genres. They were so confident you could make a release quality recording with iD22 they decided to get out in the field and record three different artists varying in style. Listen to the result for yourself...

Console Style Monitor Control: Customise your control surface
iD22 has a range of incredibly flexible console style monitor control functions such as mono, polarity, dim, cut, speaker select, talkback & cue mix monitoring. They know how important it is to focus on the music and to make tracking as simple as possible they added three programmable function keys. No more time spent searching for software controlled features, just assign the monitoring functions you need to the three hardware function keys and allow the creativity to flow. Real hardware control at your fingertips!

Intuitive software: Discover just how simple it can be
They understand the need to keep things simple and iD22’s mixer app was designed with that in mind. Whether you’re creating low latency cue mixes or utilising the flexible monitor control, iD22 tightly integrates the hardware and software making the recording process easy. Enabling you to concentrate on what’s really important - the music.

Built To Last: Quality deserves protection
iD22 has been designed to last, from its all-metal construction, hand finished aluminium knobs and high grade component selection, iD22 will stand up to countless late nights in the studio and days on the road.

Features:

• 10-in, 14-out Desktop Interface
• 2 x Class-A Audient Console Mic Preamplifiers
• High Performance Burr Brown AD/DA Converters
• Fully Balanced Inserts
• ADAT Input & Output for Expandability
• 1 x Discrete JFET Instrument Input
• Low Latency DSP Mixer
• Main and Alternative Speaker outputs
• Independent Class-AB Headphone Output
• User Defined Function Keys
• Full Monitor Control Functionality (software controlled)
• USB2.0 Compliant
• 24bit/96khz
• All-Metal Enclosure
• Over £500 worth of plugins and software with ARC

Specifications:

Microphone Preamplifier:

(measured to insert send)

• Mic Gain: -10 to +60 dB (-10dB Pad)
• Line Gain: -20 to +40 dB (-10dB Pad)
• Phantom Power: 48v +/-4v @ 10mA/Channel
• Mic EIN: <-125dBu
• CMRR: >80dB @ 1kHz
• Maximum Input Level: +22dBu (+32dBu with Pad)
• Input Impedance (Mic): >3k? Balanced
• Input Impedance (Line): >10k? Balanced
• Frequency Response: +/-0.5dB 10Hz to 100kHz
• Crosstalk: <-90dBu @ 1kHz & 10kHz
• THD+N @ 0dBu (1kHz): 0.0015% (-96dBu)
• SNR: 96dB
• HPF: -3dB @ 100Hz, 2nd Order (12dB/Octave)
• XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
• 1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)

D.I (Channel 1):

(measured to insert send)

• D.I Gain: -16 to +54 dB (-10dB Pad)
• Maximum Input Level: +16dBu (typical), +22dBu
• Input Impedance: 1Meg? Unbalanced
• Frequency Response: +/-0.5dB 10Hz to 50kHz
• THD+N @ 0dBu (1kHz): <0.03% (-70dBu)
• SNR: 93dB
• 1/4" Jack: Tip (Hot) & Sleeve (Shield)

Insert Sends (Mic Pre Out):

• Maximum Output Level: +22dBu
• Output Impedance: <100? Balanced
• 1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)

Power Supply:

• 12VDC Centre Positive DC Adapter - >1.5Amps
• Internally conditioned to provide +48VDC, +/-15VDC & low voltage rails for digital processing core & converters.
• iD22 cannot be bus powered for quality reasons.

ADC Line InputS (Insert Returns):

(measured at optical output under AES-17)

• Maximum Input Level: +18dBu
• Digital Reference Level: 0dBFS = +18dBu
• Input Impedance: >10k? Balanced
• Frequency Response: +/-0.5dB 10Hz to Fs/2
• Crosstalk: -100dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.002% (-94dB)
• THD+N @ -6dBFS (1kHz): <0.0015% (-97dB)
• Dynamic Range:
  • 117dB un-weighted
  • 120dB A-weighted
• 1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)

DAC Outputs (1-4):

(measured from optical input under AES-17)

• Maximum Output Level: +18dBu
• Digital Reference Level: 0dBFS = +18dBu
• Output Impedance: <100? Balanced
• Frequency Response: +/-0.5dB 5Hz to Fs/2
• Crosstalk: -110dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.0008% (-101dB)
• Dynamic Range:
  • 110dB un-weighted
  • 114dB A-weighted
• 1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)

Headphone Output (5&6):

(measured from optical input under AES-17)

• Maximum Output Level: +18dBu
• Digital Reference Level: 0dBFS = +18dBu
• Output Impedance: <50? Balanced
• Frequency Response: +/-0.5dB 5Hz to Fs/2
• Crosstalk: -110dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS(
