American DJ HYDRO PROFILE IP65 CMY Color Mixing LED Moving Head Light

American DJ HYDRO PROFILE IP65 CMY Color Mixing LED Moving Head Light

The Hydro Profile is ADJ’s first weatherproof moving head profile fixture, which combines a potent 660-Watt cool white LED light engine with an impressive 25,000+ Lumens, and an expansive feature set to deliver a truly powerful and versatile luminaire. It is part of ADJ’s Hydro Series of robust IP65-rated moving heads, which are all designed for a demanding life on the road. They can be used outdoors in any weather as well as for indoor productions where they are protected against everything from dust and smoke residue to spilt drinks and humidity.

Features:

• Motorized Focus
• 2 Frost Filters
• Motorized Zoom: 6 ~ 45 degrees
• 4 Blade Framing System (Rotatable)
• Iris
• Animation Wheel
• 2 Prism FX: Rotating 5-facet Linear & rotating 6-facet Circular
• 0-100% smooth dimming
• Various strobe speeds
• 2 cooling fans

Specifications:

• Light Source:
  • 660W Cool White LED Engine (50,000 hr.)
  • 25,000+ Lumens
• Color Wheel:
  • CMY color mixing system
  • Variable CTO flag
  • Color wheel with 6 dichroic colors + white (includes CTB and High CRI filters)
  • Colors on wheel are removable and replaceable
• GOBO Wheel:
  • (1) Rotating Gobo wheel with 7 Gobos
  • (1) Static Gobo wheel with 8 Gobos
  • All Gobo’s are replaceable
  • Gobo Shake Effect on both wheels
  • Aluminum Gobo size: 23mm (outer); 19mm (viewable); 0.5mm (thickness)
  • Glass gobo size: 23mm (outer); 19mm (viewable); 3.3mm (thickness)
• Prisms:
  • Prism Wheel 1: Rotatable 6-facet Circular
  • Prism Wheel 2: Rotatable 5-facet Linear
  • Both Prisms are indexable
• Frost Filters:
  • Frost 1: Heavy frost for wash effect
  • Frost 2: Medium frost creates lightly blurred edges for Gobo and Prism FX
• Control:
  • 3 DMX Channel Modes: 36/50/57
  • Color LCD display with 6-button function menu
  • Control Mode: DMX512 or internal programs
  • 6 Dim Modes: Standard, Stage, TV, Architectural, Theatre, Stage2
  • 4 Dim Curves: Square, Linear, Inv. Square, and S. Curve
  • Selectable LED Refresh Rates (900 Hz~25K Hz)
  • 0-100% smooth dimming
  • Various strobe speeds
  • With Wired Digital Communication Network
  • RDM (Remote Device Management)
• Pan/Tilt:
  • Pan: 630 degrees
  • Tilt: 270 degrees
• Connections:
  • DMX Connections: 5-pin XLR In/Out
  • Power Connections: IP65 PowerLock Input
• Electrical:
  • Multi-voltage operation: 100-240V, 50/60Hz
  • Max power consumption: 1088W
• Dimensions & Weight:
  • Dimensions (LxWxH): 12.20" x 17.00" x 28.35" (310x432x720mm)
  • Weight: 81.4lbs (37kg)
