ADJ Vizi Beam 12RX High Powered Beam Moving Head

ADJ Vizi Beam 12RX High Powered Beam Moving Head

The Vizi Beam 12RX is high powered beam moving head powered by the brilliant 260W Philips® Platinum 12R LL MSD Discharge Lamp (6,000 hr.). It produces a razor sharp 2-degree beam of light. It comes with 14 colors + open (with color indexing), 16 GOBOs + open (with GOBO indexing), two rotating prisms and a frost filter for wash effects.

The Vizi Beam 12RX offers 2 DMX modes (14 or 16 channels) and RDM control options. It has 3-pin and 5-pin DMX In/Out connections and PowerLock In/Out connection to daisy chain the power from one fixture to the next. It has a color display with 4-button internal menu system.

Features:

• 260W Philips® Platinum 12R LL MSD Discharge Lamp (6,000 hr.)
• Color temperature: 7800K
• Motorized Focus + 16-bit fine focus
• 2-degree beam angle
• Frost Filter to create wash effect
• High quality glass lens
• 2 Rotating prisms: 6-facet Linear and 24-facet Circular
• 0-100% smooth dimming
• Various strobe speeds
• USB firmware update port
• Fan cooled
• 14 dichroic colors + white (Includes CTO, CTB & UV)
• Indexable color wheel for split colors
• 16 static GOBOs + open (4 GOBOs are beam reducers)
• GOBO Shake Effect
• Rotating, 6-facet linear and 24-facet circular
• 2 DMX Channel Modes: 14/16 Channels
• Color LCD display with 4-button function menu
• Control Mode: DMX512, RDM or internal programs
• 0-100% smooth dimming
• Various strobe speeds
• USB firmware update port
• With Wired Digital Communication Network
• Pan: 540 degrees (plus 16-bit fine pan)
• Tilt: 270 degrees (plus 16-bit fine tilt)
• DMX Connections: 3-pin & 5-pin XLR In/Out (Data link max: 32 fixtures)
• Power Connections: PowerLock In/Out to daisy chain power
• Multi-voltage operation: 100-240V, 50/60Hz
• Max power consumption: 384W (@120V), 371W (@230V)
• Dimension: 10” (L) x 13.75” (W) x 22.25” (H) / 253 x 350 x 566mm
• Weight: 39.7 lbs. / 18 kg.
