Eliminator MEG560 Mega Flat PAK EP - LED With Wired Digital Communication Network
The Eliminator Lighting Mega Flat Pak EP is a convenient solution for the mobile entertainer to provide uplighting or mobile stage at any event. This lighting system includes: 4x Eliminator Lighting Mega Par Profile EP Pars, 4x (1M/3ft.) IEC to Edison power cables, 3x (6ft/2M) DMX Cables and a soft transport bag.
Mega Par Profile EP Specifications:
Source:
- 107x 10mm LEDs (26 Red, 45 Green, 36 Blue LEDs) + 1 3W UV LED)
- Light output: 345 LUX @ 2M; 92 LUX @ 4M (30-degree beam)
- Beam Angle: 30 degrees
- Long Life LEDs (50,000 hrs.)
Features:
- Smooth RGB+UV Color Mixing (fast or slow color change operation)
- Power & DMX Ins/Outs sit sideways so the unit can be set flat on the ground or set inside truss
- Display Inversion Mode
- Color strobe effect
- Compatible with ADJ LED RC2 wireless infrared remote control up to 30 ft./ 10M (sold separately)
Control:
- 5 DMX Channel modes: 4/5/6/9/10 channels
- 5 Operational modes: RGB+UV Dimmer Mode, Sound Active Mode, Auto Run Mode, Static Color Mode, & DMX Controlled
- 16 Sound Active shows
- 32 Built-in shows (16 Color Changing Shows & 16 Color Fading Shows)
- 64 built-in Color Macros
- Stand Alone or Primary/Secondary Configuration
- 5 Dimmer Curves (Standard, Stage, TV, Architectural, & Theatre)
- With Wired Digital Communication Network
- Electronic Dimming: 0-100%
- 4-button function display
Connections:
- 3-pin DMX In/Out
- IEC AC IN/OUT on rear to daisy chain power (up to 33 @ 120V and 60 @ 230V)
Electrical:
- Multi-voltage Operation: AC 100 - 240V, 50/60Hz
- Power Draw: 16W Max
Dimensions & Weight:
- Dimensions (LxWxH): 9”x 8.75”x 3.5”/ 225x220x85mm
- Weight: 3 lbs./ 1.1 kg.
What’s Included:
- Includes scissor yoke to hang on truss, mount on a wall or set on the ground
- Power cable length: 1.8 meter (IEC)
- 107x 10mm LEDs (26 Red, 45 Green, 36 Blue LEDs) + 1 3W UV LED)
- Light output: 345 LUX @ 2M; 92 LUX @ 4M (30-degree beam)
- Beam Angle: 30 degrees
- Long Life LEDs (50,000 hrs.)
Features:
- Smooth RGB+UV Color Mixing (fast or slow color change operation)
- Power & DMX Ins/Outs sit sideways so the unit can be set flat on the ground or set inside truss
- Display Inversion Mode
- Color strobe effect
- Compatible with ADJ LED RC2 wireless infrared remote control up to 30 ft./ 10M (sold separately)
Control:
- 5 DMX Channel modes: 4/5/6/9/10 channels
- 5 Operational modes: RGB+UV Dimmer Mode, Sound Active Mode, Auto Run Mode, Static Color Mode, & DMX Controlled
- 16 Sound Active shows
- 32 Built-in shows (16 Color Changing Shows & 16 Color Fading Shows)
- 64 built-in Color Macros
- Stand Alone or Primary/Secondary Configuration
- 5 Dimmer Curves (Standard, Stage, TV, Architectural, & Theatre)
- With Wired Digital Communication Network
- Electronic Dimming: 0-100%
- 4-button function display
Connections:
- 3-pin DMX In/Out
- IEC AC IN/OUT on rear to daisy chain power (up to 33 @ 120V and 60 @ 230V)
Electrical:
- Multi-voltage Operation: AC 100 - 240V, 50/60Hz
- Power Draw: 16W Max
Dimensions & Weight:
- Dimensions (LxWxH): 9”x 8.75”x 3.5”/ 225x220x85mm
- Weight: 3 lbs./ 1.1 kg.
What’s Included:
- Includes scissor yoke to hang on truss, mount on a wall or set on the ground
- Power cable length: 1.8 meter (IEC)
- 5 DMX Channel modes: 4/5/6/9/10 channels
- 5 Operational modes: RGB+UV Dimmer Mode, Sound Active Mode, Auto Run Mode, Static Color Mode, & DMX Controlled
- 16 Sound Active shows
- 32 Built-in shows (16 Color Changing Shows & 16 Color Fading Shows)
- 64 built-in Color Macros
- Stand Alone or Primary/Secondary Configuration
- 5 Dimmer Curves (Standard, Stage, TV, Architectural, & Theatre)
- With Wired Digital Communication Network
- Electronic Dimming: 0-100%
- 4-button function display
Connections:
- 3-pin DMX In/Out
- IEC AC IN/OUT on rear to daisy chain power (up to 33 @ 120V and 60 @ 230V)
Electrical:
- Multi-voltage Operation: AC 100 - 240V, 50/60Hz
- Power Draw: 16W Max
Dimensions & Weight:
- Dimensions (LxWxH): 9”x 8.75”x 3.5”/ 225x220x85mm
- Weight: 3 lbs./ 1.1 kg.
What’s Included:
- Includes scissor yoke to hang on truss, mount on a wall or set on the ground
- Power cable length: 1.8 meter (IEC)
- Multi-voltage Operation: AC 100 - 240V, 50/60Hz
- Power Draw: 16W Max
Dimensions & Weight:
- Dimensions (LxWxH): 9”x 8.75”x 3.5”/ 225x220x85mm
- Weight: 3 lbs./ 1.1 kg.
What’s Included:
- Includes scissor yoke to hang on truss, mount on a wall or set on the ground
- Power cable length: 1.8 meter (IEC)
- Includes scissor yoke to hang on truss, mount on a wall or set on the ground
- Power cable length: 1.8 meter (IEC)
