Description

Neumann KH-810-G 10-Inch Active Subwoofer with 7.1 High Definition Bass Management

The KH 810 is an answer to the demands by offering a 7.1 High Definition Bass Manager™. The flexibility of this bypassable 7.1 bass manager means it is also compatible with all standard consumer formats from mono through to the latest 7.1 HD systems.

Eight channels of analog ensures flexible interconnectivity for modern studios. Four-mode LFE-channel processing guarantees compatibility across all formats and industries. Forth-order crossovers and flexible acoustical controls allow for seamless system integration. Built-in volume control and a hardware remote control allows for centralized system control independent of the source, and the electronics can be remote located to reduce cabling. From Mono to 3D, there are uses for the KH 810 in many different system configurations.

Features:

  • 7.1 Channel HD Bass Management
  • 10" Front-Firing Driver
  • 4-Mode LFE Processing
  • 4th Order Crossover
  • 8-Channel System Volume Control
  • Daisy-Chain Capable
  • RS-232 Remote Port
  • Integrated Electronic Limiter

Specifications:

  • Number of Included Monitors: Single Monitor
  • Enclosure: Bass-Reflex/Ported, Shielded
  • Total Power Output: 160 W RMS / 200 W Peak
  • Drivers:
    • Subwoofer Drivers: 1x 10" / 25.4 cm Cone
  • Performance:
    • Frequency Range: 18 Hz to 300 Hz ± 3 dB (-3 dB)
    • Frequency Response: 19 Hz to 300 Hz ± 2 dB
    • Maximum Sound Pressure Level (SPL): 110.7 dB
    • Dynamic Range: 110 dBA
    • Total Harmonic Distortion (THD): 0.001%
    • Maximum Input Level: +19 dBu
    • Analog Input Sensitivity/Gain: +6 / -8 dBu (Fixed)
    • Self-Generated Noise: Less Than 20 dBA (at 3.93" / 10 cm)
    • Protections and Limiting: Peak Limiter and Thermal Limiting
    • CMRR: 60 dB
  • Signal Processing:
    • Filters: High-Pass at 6.5 Hz, 12 dB/Octave Slope
    • Parametric EQ: -12 to +4 dB Between 20Hz and 120Hz, Q: 1 to 8
    • Crossover Frequency: 80 Hz, 24 dB/Octave Slope
  • Connectivity:
    • Audio I/O: 1x XLR 3-Pin Balanced Input (13 Kilohms)
  • Power:
    • AC Input Power:
    • 100 to 120 VAC, 60 Hz
    • 220 to 240 VAC, 50 Hz
    • Power Consumption:
    • 20 W (Idle)
    • 290 W (Maximum)
  • Physical:
    • Color: Black
    • Orientation: Vertical
    • Enclosure Material: Metal Grille, Wood
    • Dimensions (W x H x D): 13 x 14.2 x 25.4" / 330 x 360 x 645 mm
    • Weight: 57.2 lb / 26.0 kg
