Elation FUZE-MAX-PROFILE LED Moving Head Fixture
The FUZE MAX PROFILE is a full spectrum automated LED framing fixture designed for theater, television and a wide array of other precision lighting applications. The 92 CRI engine utilizes an 800W 5-color homogenized LED array consisting of Red, Green, Blue, Mint, and Amber sources. The carefully tuned LEDs ensure accurate color reproduction and dynamic whites while delivering a powerful output of over 21,000 lumens. Virtual color temperature, Magenta / Green adjustment plus CMY emulation provide the designer with immediate access to the impressive LED color array.
The FUZE MAX PROFILE is designed for any application where fully automated framing fixture with outstanding and compelling color range and quality is required. A rotating gobo wheel, fixed gobo wheel, animation wheel, dual frost, prism and iris round out its comprehensive feature set in this quiet and extremely powerful automated framing fixture.
Features:
- Full Spectrum 800W RGBMA LED Engine
- Precise dynamic whites from 2400 - 8500K
- Instant color changes, Natural color transitions
- Rich and intense primary colors
- Rotating and Fixed Gobos plus Animation Wheel
- Full Blackout Framing System
- Iris, Prism, and Dual Frost
- Wide Zoom Range from 7° to 53°
- Large 140mm front aperture
Specifications:
- Source:
- 800W 6,500K RGBMA LED Engine
- 30,000 Hour Average LED Life*
- Photometric Data:
- 21,000 Total Lumen Output
- CRI 92
- Zoom Range: 7° - 53°
- Beam Angle: 6.6° - 50.3°
- Field Angle: 7.8° - 55°
- Effects:
- Motorized Zoom
- 4 Rotating Full Blackout Framing Blades, +/- 60° Index
- Dual Variable Frost Filter (Medium/Wash)
- 4 Facet Round, 4 Facet Linear Prism
- Motorized Iris
- Variable 16-bit Dimming Curve Modes
- High Speed Electronic Shutter and Strobe
- Pan Angle: 540° / 630°
- Tilt Angle: 250°
- Color:
- RGBMA Color Array
- CMY Emulation
- Variable CCT 2400K - 8500K
- Green/Magenta Shift
- Virtual Gel Swatch Book
- Gobos:
- 1x 6 Rotating / Indexing Interchangeable Glass Gobos
- 1x 7 Fixed Interchangeable Glass Gobos
- Animation Wheel
- Control/Connections:
- 4 DMX Channel Modes (RGBMA 40/61) (CMY 38/57)
- 16-bit Pan, Tilt, and Dimming Control
- DMX Adjustable LED Frequency
- DMX, RDM, Art-NET, sACN Protocol Support
- 4 Button Touch Control Panel
- Full Color 180° Reversible LCD Menu Display
- 16-bit Resolution Adjustable Movement
- 5pin DMX In/Out
- Locking Ethernet In/Out
- IP65 Locking Power In
- Wired Digital Communication Network
- Size/Weight:
- Length: 18.19” (462mm)
- Width: 21.26" (540mm)
- Width with Snoot: 23.2" (590mm)
- Vertical Height: 28.3" (719mm)
- Vertical Height with Snoot: 30.4" (771mm)
- Center Spacing (no snoot): 26.1in (662mm)
- Center Spacing (with snoot): 29.8in (757mm)
- Weight: 76.3 lbs. (34.6kg)
- Electrical/Thermal:
- AC 100-240V - 50/60Hz
- 1126W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
- BTU/hr (+/- 10%): 3839.66
- Optional Accessories: 7030100797 - Snoot
- Approvals/Ratings: CE | cETLus | IP20 | FCC
