Disguise EX Media Server
Disguise EX Media Server
SKU:
Available options
Description
Disguise EX Media Server
The most competitive price-to-performance media server on the market, the EX range packs a punch and opens the power of the world's most advanced live visual experience technology to a wider range of productions. Get the pixel-perfect video playback, exceptional performance and creative flexibility expected from Disguise, in a modular, scalable architecture. Versatile From live shows and corporate events to fixed installations, the EX offers unmatched playback capabilities to meet your project's demands. Durable Engineered in a ruggedised 2U chassis, the EX is built for long-lasting durability and seamless integration into any setup. Scalable Easily scale your production with the EX. Run it as part of a network for redundancy and failover with other EX machines. Control The EX can also run as a director and editor with the VX and GX range, distributing video playback across complex systems. Integrated Unlock our Designer pixel mapping software and reap all the benefits of one integrated workflow from concept to delivery. Support Benefit from our unbeatable support packages with global service centres, 24/7/365 support and a global community of trained operators, ensuring your production will run without a hitch.
The Disguise EX Media Server is the EX 2, EX 2C, EX 3+.
Specifications:
| EX 2 | EX 2C | EX 3+ | |
| Video output | 2x DisplayPort 1.4 | 2x DisplayPort 1.4 | 3x DisplayPort 1.4 |
| Video input | Input via NDI only | Up to 2x 4K DCI inputs** or 4x Full-HD inputs via any combination of the following: 1x HDMI 2.0 capture (HDMI connector), 2x 12G SDI inputs via Ports A and C (HD-BNC connector) and 4x 3G SDI inputs (HD-BNC connector) | Up to 3x 4K DCI inputs** or 4x Full-HD inputs via any combination of the following: 1x HDMI 2.0 capture (HDMI connector), 2x 12G SDI inputs via Ports A and C (HD-BNC connector) and 4x 3G SDI inputs (HD-BNC connector) |
| High-speed network | 2x100Gb/sec (QSFP28) | 2x 100Gb/sec (QSFP28) | 2x 100Gb/sec (QSFP28) |
| CPU | AMD EPYV 2.4Ghz | AMD EPYC 2.4Ghz | AMD EPYC 2.45Ghz |
| GPU | NVIDIA RTX 4000 Ada | NVIDIA RTX 4000 Ada | NVIDIA RTX 4000 Ada |
| Motherboard | PCIe 5.0 | PCIe 5.0 | PCIe 5.0 |
| Storage | 1.92TB Removeable NVMe SSD | 1.92TB Removable NVMe SSD | 3.84TB Removable NVMe SSD |
