DiGiCo SD11 Digital Mixing Console

DiGiCo SD11 Digital Mixing Console

The DiGiCo SD11 is a 19" rack-mountable console featuring a 15" touchscreen and 12 touch-sensitive faders housed in a rugged steel and aluminium chassis.

It provides 48 input channels at 48/96 kHz with DiGiCo processing including Dynamic EQ, Multiband compression, and DiGiTuBes emulation.

The SD11 provides 12 GEQs, six stereo effects, eight control groups, 24 busses, and an 8×8 matrix for flexible signal routing.

It's I/O includes 16 mic/line inputs, 8 line outputs, 2 AES, 1 MADI, D-Rack connectivity, and optional Optocore support.

The option to add SoundGrid module allows access to 32 Waves MultiRacks and expand I/O to 128 channels.

The SD11 is available with MADI Only, One Multi-Mode Optics HMA or One Multi-Mode Optics ST

The DiGiCo SD11 Digital Mixing Console is also available in the SD11B or SD11i versions.

Features:

I/O Rack:

• DiGiCo SD-Rack

• DiGiCo SD-MiNi Rack Stage Box

• DiGiCo SD-Nano Rack

• DiGiCo D-Rack

• DiGiCo D2-Rack

• DiGiCo Purple Box Convertor

• DiGiCo Orange Box I/O Rack

• DiGiCo Little Red USB Audio Interface

• DiGiCo Little Blue Box USB Audio Interface

• DiGiCo UB MADI USB Audio Interface

• DiGiCo Waves SoundGrid I/O Rack
• DiGiCo RR-PSU Power Supply Unit
