DiGiCo SD11 Digital Mixing Console
The DiGiCo SD11 is a 19" rack-mountable console featuring a 15" touchscreen and 12 touch-sensitive faders housed in a rugged steel and aluminium chassis.
It provides 48 input channels at 48/96 kHz with DiGiCo processing including Dynamic EQ, Multiband compression, and DiGiTuBes emulation.
The SD11 provides 12 GEQs, six stereo effects, eight control groups, 24 busses, and an 8×8 matrix for flexible signal routing.
It's I/O includes 16 mic/line inputs, 8 line outputs, 2 AES, 1 MADI, D-Rack connectivity, and optional Optocore support.
The option to add SoundGrid module allows access to 32 Waves MultiRacks and expand I/O to 128 channels.
The SD11 is available with MADI Only, One Multi-Mode Optics HMA or One Multi-Mode Optics ST
The DiGiCo SD11 Digital Mixing Console is also available in the SD11B or SD11i versions.
Features:
- 48 Input Channels
- 24 Aux / Sub-Group Busses
- LR/LCR Master Buss
- 8 x 8 Full Processing Matrix
- 83 Dynamic Equalizers
- 48/96kHz Sample Rate
