Denon Pro DN-205W 2-Way In-Wall Speaker

Two-Way In-Wall Speaker

The Denon Professional DN-205W two-way wall speaker is designed for commercial installations and is compatible with 70V/100V/8-ohm systems. The assembly is composed of two 5-1/4 inch carbon fiber woofers for superior bass and mid-range reproduction, and a 1-inch silk dome aluminum tweeter for smooth high-end.

Along with full-range response, the unit also features a two position high-frequency roll-off for additional acoustic control. The paintable, magnetic grille enables the DN-205W to completely blend into its surroundings for a profesional, clean installation.

Features:

• Two 5-1/4" carbon fiber woofers
• 1" silk and aluminum dome swivel tweeter
• Full-range frequency response
• 50W power handling (100W peak)
• Paintable, magnetic speaker grille
• EN 54-24 compliant

Specifications:

System Specification

• Low Frequency Drivers: 2x 5.25" (133mm) carbon fiber woofers
• High Frequency Driver: 1" (25mm) aluminum and silk swivel dome tweeter
• Frequency Response: 62 - 20kHz
• High-frequency Roll-off: Two positions, -3dB and -6dB
• Power Handling: 50W RMS (100W peak)
• Sensitivity: 88dB (1W/1m)
• Speaker Connection: Push terminals for wire up to 14AWG
• Regulatory Compliance: EN 54-24

Transformer Power Taps

• 70V: 30, 15, 7.5W
• 100V: 30, 15W
• Bypass: 8?

Physical

• Grille Material: Steel
• Overall Dimension: 14.7 x 7.4 x 3.8" (373 x 187 x 98mm)
• Cut-out Hole: 13.3 x 6" (338 x 152mm)
• Wall Clearance: 3.66" (93mm)
• Weight:7.7 lbs. (3.5kg)
