Barco G100‑W22 Projector

Barco G100‑W22 22,000 Lumen, WUXGA, Single-chip Laser Phosphor Projector

The Barco G100-W22 delivers exceptional image performance with 22,000 lumens of brightness, enabling stunning projections in both indoor and outdoor environments.

This single-chip laser-phosphor projector combines superior image quality with HDMI 2.0 support for deep colour palettes and qualitative visuals. Built for complete flexibility, the G100-W22 features an extensive GC-lens range with throw ratios from 0.38 to 10.8, allowing you to project from short or long distances with 360° orientation capabilities.

The stable lens holder ensures reliable blending and non-moving images in multi-channel setups, ideal for planetariums, domes, theatres, and projection mapping installations. Barco's Projector Toolset software provides intuitive installation and management from your computer, with advanced blending and warping capabilities for seamless multi-channel configurations. Engineered for reliability, the G100-W22 features a laser-phosphor light source with advanced cooling that delivers over 20,000 hours of operation without lamp changes, significantly reducing maintenance costs.

The projector operates efficiently at maximum ambient temperatures of 50°C (122°F) with noise levels as low as 42 dB, making it suitable for any creative project requiring performance, flexibility, and long-term dependability.

Features:

• Single-chip high-brightness projections
• Up-to-date input capabilities & future-proof design
• Full operational flexibility through wide lens range
• 1 Chip DLP
• Laser Phosphor
• 22K Lumens
• HDBaseT Compliant
• 24/7 Operation
• 3D Ready
• Rugged
• Low Noise
• Bright

Specifications:

• Projector type: Single chip DLP laser phosphor projector
• Resolution: 1,920 x 1,200 (WUXGA) - 0.96" DLP chip
• Brightness:
  • 22,000 ISO lumen / 20,600 centre lumen / 18,500 ANSI lumen
  • 23,750 ISO lumen (Super Bright mode)*
• Brightness uniformity: 90%
• Contrast ratio: 1,100:1 sequential; 5,500:1 dynamic; Extreme black: 100,000:1
• Light source: Laser phosphor
• Light source lifetime: Up to 20,000hrs
• Aspect ratio: 16:10
• Orientation: 360° rotation, no restrictions
• Sealed DLP core: Yes
• Colour correction: Yes
• CLO (constant light output): Yes
• Keystone correction: Yes
• Image processing: Embedded warp & blend. Also available via Projector Toolset
• 3D: Active and passive stereoscopic 3D
• Lens type:
  • GC lenses - 0.65-0.75:1 / 0.84-1.02:1 / 1.02-1.36:1 / 1.2-1.5:1 / 1.5-2.0:1 / 2.0-4.0:1 / 4.0-7.2:1 / 7.2-10.8:1
  • FLDX lens - 0.38 : 1 UST 90°
• Optical lens shift:
  • Vertical up to 120%, depending on lens

  • Horizontal up to 50%, depending on lens

  • Motorized zoom and focus

  • Motorized lens shift
• Inputs: 2x HDMI 2.0b / DisplayPort 1.2a / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin)
• Input resolutions:
  • Up to 4K UHD @60Hz
  • Refresh rates: 24Hz to 60Hz for WUXGA and 4KUHD (4096 x 2160 / 3840 x 2160)
  • 4K input signals will be scaled to the projector’s output resolution
• Software tools: Projector Toolset
• Control: IR, RS232, RJ45, USB type A
• Network connection: 10/100 Ethernet, RJ45
• Power requirements: 100-240V / 50-60Hz
• Power consumption: 100-240V / 50-60Hz

• Standby power: less than 0.5W
• BTU per hour: 4095 BTU/h minimal, 4710 BTU/h maximum
• Noise level (typical at 25°C/77°F): 38dB(A) - 42dB(A) depending on the used mode

• Operating temperature: 0 - 50 °C (sea level)
• Operating humidity: 10 - 85% RH, non-condensing
• Storage temperature: -10 to 60 °C
• Storage humidity: 5 - 90% RH, non-condensing
• Dimensions (WxLxH): without feet: 650 x 710 x 251 mm / 25.6 x 27.9 x 9.9 in
• Weight: without lens: 54 kg / 119.0 lbs
• Standard accessories: Power cord, wireless remote control
• Certifications: CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
• Warranty: Limited 3 years parts and labour
• *Note:  Only available on 220V input power and with lifetime of 16.500hrs @25°C/77°F
