Barco FS40‑4K MKII Projector

Barco FS40‑4K MKII Rock-solid and Powerful 4K LED Projector for NVG Training

The Barco FS40-4K MKII is a true solid-state LED projector engineered for the most demanding simulation and training environments. Featuring native WQXGA resolution with 4K capability (3840 x 2400), dual RGB and dedicated IR light sources enable independent control of visible and infrared intensity, perfect for simulating daytime and nighttime training scenarios. Built for extreme reliability, the FS40-4K MKII combines Barco Pulse electronics with sealed DLP optical technology and a solid magnesium alloy baseplate. With no moving parts and shock-resistant construction, it's designed to perform flawlessly on motion platforms in any orientation. Dual iris and optical filters deliver superior contrast and deep blacks for exceptional image clarity. Engineered for lowest total cost of ownership, the FS40-4K MKII requires no lamp changes or colour adjustments for up to 75,000 hours of operation. Barco Constant Light Output (CLO) ensures predictable brightness performance throughout the projector's lifespan. Single Step Processing (SSP) technology delivers high-resolution images at higher frame rates with lower latency than competing solutions. Optional intelligent high-efficiency air filters provide enhanced protection in dusty and harsh environments. A vision to trust for mission-critical simulation training.

Features:

• Extreme detail up to 4K (3840 x 2400) resolution
• Night Vision Goggles stimulation
• True solid-state and ruggedized
• Brighter LEDs with exceptional colour fidelity
• 100-0% LED dimming for training at any time
• Barco Pulse software ensures powerful processing and lowest latency
• 4K UHD
• 1 Chip DLP
• Constant Light Output
• Pulse Processing
• 24/7 Operation

Specifications:

• Brightness: 2,870 Typical ANSI Lumens
• Contrast ratio: 1800-6000:1
• IR for NVG: Yes
• Brightness uniformity: 90%
• Aspect ratio: 16:10
• Projector type: 1DLP RGB LED
• Resolution: 3,840 x 2,400 (4K) / 2,560 x 1,600 (native)
• Lens type: FLD+/FLDX
• Optical lens shift:
  • Vertical up to 146%, depending on lens

  • Horizontal up to 70%, depending on lens

  • Motorized zoom and focus (+ lens memory FLDX lenses)

  • Motorized lens shift (with position memory on all lenses)
• Colour correction: P7 RealColor
• CLO (constant light output): Yes
• Light source: RGB LED
• Light source lifetime:
  • Minimum 50,000 hours @ full power

  • Up to 75,000 hours, depending on mode of operation
• Sealed DLP core: Yes
• Orientation: 360° rotation, no restrictions
• 3D: Active stereoscopic 3D
• Image processing: Embedded warp & blend engine
• Keystone correction: Yes
• Inputs:
  • 2x DP1.2

  • 2x dual link DVI-I

  • HDBaseT upgradable

  • HDMI™ 2.0 (HDCP2.2, HDR10)

  • RJ 45 Ethernet

  • RS232 in

  • 2x USB

  • 12v out
• Input resolutions:
  • Including and up to:

  • 3,840 x 2,400 @ 60Hz

  • 3,840 x 2,160 @ 60Hz
  • 4,096 x 2,160 @ 60Hz
  • 2,560 x 1,600 @ 120Hz
• Input colour depth: Up to 12-bit, depending on configuration
• Software tools: Projector Toolset
• Control: IR, RS232, RJ45
• Network connection: IR, RS232, RJ45
• Power requirements: 100-240V / 50-60Hz
• Power consumption: 520 W typical, 700 W maximum
• BTU per hour: 1,707 BTU/h typical, 1,945 BTU/h max
• Noise level (typical at 25°C/77°F): 33 dB(A)
• Operating temperature: 10 - 40 °C (sea level)
• Storage temperature: -20 to 60 °C
• Operating humidity: 20 - 80% RH
• Storage humidity: 10 -90% RH
• Dimensions (WxLxH): 450 x 457 x 244 mm / 17.7 x 18.0 x 9.6 in
• Weight: 21.5 kg / 47.4 lbs
• Standard accessories: Power cord, wireless remote control
• Certifications: CE, FCC Class A and cNus
• Warranty: Limited 5 years parts and labour, extendable
