Yamaha DZR12W 2000-Watt 12-Inch Powered Loudspeaker White
The DZR12 is 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive 139dB SPL. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR12 realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
Features:
- 2-way powered loudspeaker with a 2” HF and a 12" LF
- Maximum 139dB SPL and 39Hz-20kHz frequency range is ideal for today’s sound engineering demands
- High power 2000W Class-D amplifier module
- 96kHz DSP and FIR filter for true high-resolution sound with super low latency
- Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
- Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
- D-Contour and highly reliable protection circuits
- Floor monitoring setting enables mirroring configuration
- Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
Specifications:
- Speaker Type: 2-way, Bi-amped Powered Speaker, Bass-reflex
- Frequency Range (-10dB): 39Hz - 20kHz
- Covergae Area: H90ﾟ x V60ﾟ (Rotatable)
- Components LF: 12" Cone, 3" Voice Coil, Neodymium magnet
- Crossover: 1.8kHz (FIR-X)
- Sampling Frequency Rate: 96kHz and FIR Filter
- I/O Connectors: SpeakON NL4MP x 2 (Parallel)
- A/D D/A Converters: 96kHz AD/DA
- Maximum output level (1m; on axis): 139dB SPL
- Amplifier Class: Class-D
- Cooling: Fan cooling, Variable speeds
- Power Consumption: 45W (Idle), 150W (1/8)
- Handle: Aluminium die-cast, Top x1, Side x1
- Pole Socket:Φ35 mm x2 (0° or -7°)
- Dimensions (WxHxD): 16.1" x 25.4" x 15.5"
- Weight: 21.4kg (47.2lbs)
Power Rating
- Dynamic: 2000W (LF: 1000W, MF/HF: 1000W)
- Burst (20ms): 1100W (LF: 1000W, MF/HF: 100W)
- Continuous: 950W (LF: 850W, MF/HF: 100W)
I/O Connectors
Specifications:
- Speaker Type: 2-way, Bi-amped Powered Speaker, Bass-reflex
- Frequency Range (-10dB): 39Hz - 20kHz
- Covergae Area: H90ﾟ x V60ﾟ (Rotatable)
- Components LF: 12" Cone, 3" Voice Coil, Neodymium magnet
- Crossover: 1.8kHz (FIR-X)
- Sampling Frequency Rate: 96kHz and FIR Filter
- I/O Connectors: SpeakON NL4MP x 2 (Parallel)
- A/D D/A Converters: 96kHz AD/DA
- Maximum output level (1m; on axis): 139dB SPL
- Amplifier Class: Class-D
- Cooling: Fan cooling, Variable speeds
- Power Consumption: 45W (Idle), 150W (1/8)
- Handle: Aluminium die-cast, Top x1, Side x1
- Pole Socket:Φ35 mm x2 (0° or -7°)
- Dimensions (WxHxD): 16.1" x 25.4" x 15.5"
- Weight: 21.4kg (47.2lbs)
Power Rating
- Dynamic: 2000W (LF: 1000W, MF/HF: 1000W)
- Burst (20ms): 1100W (LF: 1000W, MF/HF: 100W)
- Continuous: 950W (LF: 850W, MF/HF: 100W)
I/O Connectors
- Analog I/O: Analog IN: Combo x2, Line level (Maximum +24dBu), Input impedance 20kΩ, Analog OUT: XLR3-32 x2, CH1: THRU (fix), CH2: THRU or DSP OUT
- Digital I/O: Dante: etherCON CAT5e x2 (Daisy Chain), 2 IN / 2 OUT (Fs: 44.1k, 48k, 88.2k, 96k) and Remote Control, 1000BASE-T
- AC: IEC AC inlet x1 (V-Lock)
- Others: USB2.0 Host 5V 500mA for USB memory DATA storage/load
